WK-06 series

Product Features

  • 100% SUS 304 stainless steel inside out
  • Resistant to sand
  • Resistant to aggressive water
  • Discharge casing with threaded connection. Flange optional
  • Shaft made from SUS 410 stainless steel
  • Suction strainer to prevent clogging

Applications

  • Groundwater intake/water supply
  • Municipal and industrial waters supply
  • Irrigation/raw water supply
  • Dewatering (construction sites, mines)
  • Thermal waters, pools, and springs
  • Fish farming
  • Fountains
  • Offshore
  • Pressure boosting

down-5down-4         down-7

down-3           down-8

分類: ,

Technical Data

  • 6 ” pump
  • Flow: Max. 27 m³/h-50Hz / 39 m³/h-60Hz
  • Head: Max. 450 m
  • Max. sand content: 50 g/m³
  • Liquid Temp.: 0 °C to 35 °C
  • pH values: 6 to 8
  • Installation depth: Max. 300 m

Performance Curve
WK-06-50Hz-1 WK-06-60Hz-1

Specifications

50Hz

Model DISCH TOTAL HEAD CAPACITY HEAD MOTOR MOTOR SIZE
inch M GPM M³/hr M HP kW
WK-0606 2″ / 2 1/2″ / 3″ 75 50 12 50 5 3.7 4″
WK-0608 2″ / 2 1/2″ / 3″ 99 50 12 68 7.5 5.5 4″
WK-0609 2″ / 2 1/2″ / 3″ 112 50 12 77 7.5 5.5 4″
WK-0606 2″ / 2 1/2″ / 3″ 75 50 12 50 5 3.7 6″
WK-0608 2″ / 2 1/2″ / 3″ 99 50 12 68 7.5 5.5 6″
WK-0609 2″ / 2 1/2″ / 3″ 112 50 12 77 7.5 5.5 6″
WK-0613 2″ / 2 1/2″ / 3″ 157 50 12 100 10 7.5 6″
WK-0614 2″ / 2 1/2″ / 3″ 170 50 12 110 10 7.5 6″
WK-0615 2″ / 2 1/2″ / 3″ 187 50 12 124 12.5 9 6″
WK-0617 2″ / 2 1/2″ / 3″ 215 50 12 145 12.5 9 6″
WK-0619 2″ / 2 1/2″ / 3″ 233 50 12 153 15 11 6″
WK-0620 2″ / 2 1/2″ / 3″ 248 50 12 163 15 11 6″
WK-0623 2″ / 2 1/2″ / 3″ 283 50 12 183 15 11 6″
WK-0624 2″ / 2 1/2″ / 3″ 299 50 12 192 17.5 13 6″
WK-0628 2″ / 2 1/2″ / 3″ 341 50 12 213 20 15 6″
WK-0629 2″ / 2 1/2″ / 3″ 353 50 12 220 20 15 6″
WK-0630 2″ / 2 1/2″ / 3″ 366 50 12 235 20 15 6″
WK-0635 2″ / 2 1/2″ / 3″ 425 50 12 278 25 18.5 6″

60Hz

Model DISCH TOTAL HEAD CAPACITY HEAD MOTOR MOTOR SIZE
inch M GPM M³/hr M HP kW
WK-0604 2″ / 2 1/2″ / 3″ 75 66 15 60 5 3.7 4″
WK-0605 2″ / 2 1/2″ / 3″ 94 66 15 75 7.5 5.5 4″
WK-0606 2″ / 2 1/2″ / 3″ 119 66 15 90 7.5 5.5 4″
WK-0605 2″ / 2 1/2″ / 3″ 97 66 15 75 7.5 5.5 6″
WK-0606 2″ / 2 1/2″ / 3″ 119 66 15 90 7.5 5.5 6″
WK-0607 2″ / 2 1/2″ / 3″ 137 66 15 107 10 7.5 6″
WK-0608 2″ / 2 1/2″ / 3″ 159 66 15 129 10 7.5 6″
WK-0611 2″ / 2 1/2″ / 3″ 221 66 15 167 15 11 6″
WK-0613 2″ / 2 1/2″ / 3″ 259 66 15 183 20 15 6″
WK-0614 2″ / 2 1/2″ / 3″ 276 66 15 201 20 15 6″
WK-0615 2″ / 2 1/2″ / 3″ 292 66 15 220 20 15 6″
WK-0617 2″ / 2 1/2″ / 3″ 334 66 15 250 25 18.5 6″
WK-0618 2″ / 2 1/2″ / 3″ 352 66 15 265 25 18.5 6″
WK-0619 2″ / 2 1/2″ / 3″ 369 66 15 281 25 18.5 6″
WK-0621 2″ / 2 1/2″ / 3″ 414 66 15 300 30 22 6″
WK-0622 2″ / 2 1/2″ / 3″ 432 66 15 319 30 22 6″
WK-0623 2″ / 2 1/2″ / 3″ 447 66 15 340 30 22 6″
WK-0626 2″ / 2 1/2″ / 3″ 508 66 15 399 40 30 6″
WK-0627 2″ / 2 1/2″ / 3″ 528 66 15 417 40 30 6″
