WS-17 series

Product Features

  • 100% SUS 304 stainless steel made
  • Superior hydraulics, reliability and pumping efficiency
  • Longer lifetime
  • Strong, stainless-steel quality
  • Sand resistance

Applications

  • Irrigation/ water supply
  • Groundwater intake/ water supply
  • Dewatering (pasturage, sump, pond, and mining drainage, etc.)
  • Fountains
  • Pressure boosting

down-5down-4         down-7

down-3           down-8

分類: ,

Technical Data

  • 6″ pump
  • Capacity: 17 m³/h
  • Max. sand content: 50 g/m³
  • pH values: 6 to 8
  • Liquid Temp. up to 35 °C
  • Material:
    1. Impellers/Diffusers – SUS 304
    2. Shaft -SUS431QT

Performance Curve

50Hz

Model DISCH TOTAL HEAD CAPACITY HEAD LENGTH WEIGHT Required Power
(inch) (m) L/min M³/hr. (m) (mm) (kg) HP kW
WS-1701 2-1/2″ 11.5 250 15 7 317 4.6 0.75 0.55
WS-1702 2-1/2″ 33 250 15 17 377 5.9 1.5 1.1
WS-1704 2-1/2″ 42.5 250 15 29 497 8.5 3 2.2
WS-1705 2-1/2″ 53 250 15 37 557 9.8 4 3
WS-1706 2-1/2″ 64 250 15 45 617 11.1 5 3.7
WS-1707 2-1/2″ 75 250 15 52 677 12.4 5.5 4
WS-1710 2-1/2″ 108 250 15 75 857 16.1 7.5 5.5
WS-1713 2-1/2″ 141 250 15 98 1052 20.3 10 7.5
WS-1717 2-1/2″ 184 250 15 128 12922 25.4 12.5 9.3
WS-1720 2-1/2″ 216 250 15 150 1472 29.2 15 11
WS-1722 2-1/2″ 239 250 15 168 1592 31.8 17.5 13
WS-1724 2-1/2″ 260 250 15 181 1712 34.3 17.5 13
WS-1727 2-1/2″ 291 250 15 207 1892 38.2 20 15
WS-1729 2-1/2″ 314 250 15 228 2012 40.8 25 18.5
WS-1731 2-1/2″ 335 250 15 243 2132 43.4 25 18.5
WS-1733 2-1/2″ 355 250 15 255 2252 46 25 18.5
WS-1736 2-1/2″ 390 250 15 281 2432 49.9 30 22
WS-1738 2-1/2″ 410 250 15 293 2552 52.5 30 22
WS-1740 2-1/2″ 433 250 15 322 2672 55.1 30 22

60Hz

Model DISCH TOTAL HEAD CAPACITY HEAD LENGTH WEIGHT Required Power
(inch) (m) L/min M³/hr. (m) (mm) (kg) HP kW
WS-1701 2-1/2″ 18 250 15 13 317 4.6 1.5 1.1
WS-1702 2-1/2″ 32 250 15 25 377 5.9 3 2.2
WS-1703 2-1/2″ 48 250 15 37 437 7.2 4 3
WS-1704 2-1/2″ 63 250 15 50 497 8.5 5 3.7
WS-1705 2-1/2″ 80 250 15 64 557 9.8 7.5 5.5
WS-1706 2-1/2″ 93 250 15 76 617 11.1 7.5 5.5
WS-1707 2-1/2″ 110 250 15 88 677 12.4 10 7.5
WS-1708 2-1/2″ 125 250 15 101 737 13.7 10 7.5
WS-1709 2-1/2″ 142 250 15 112 797 15 10 7.5
WS-1710 2-1/2″ 158 250 15 126 857 16.1 12.5 9.3
WS-1711 2-1/2″ 173 250 15 139 917 17.5 12.5 9.3
WS-1712 2-1/2″ 189 250 15 152 977 18.9 15 11
WS-1713 2-1/2″ 204 250 15 164 1037 20.3 15 11
WS-1714 2-1/2″ 220 250 15 178 1097 21.6 17.5 13
WS-1715 2-1/2″ 237 250 15 190 1157 22.9 17.5 13
WS-1716 2-1/2″ 254 250 15 204 1217 24.2 20 15
WS-1718 2-1/2″ 284 250 15 228 1337 26.7 20 15
WS-1720 2-1/2″ 312 250 15 257 1457 29.2 25 18.5
WS-1722 2-1/2″ 343 250 15 280 1577 31.8 25 18.5
WS-1726 2-1/2″ 410 250 15 330 1817 36.9 30 22
WS-1728 2-1/2″ 443 250 15 369 1937 38.2 35 26
WS-1730 2-1/2″ 475 250 15 393 2057 39.5 35 26
