Technical Data
- 4″ pump
- Capacity: 01 m³/h
- Max. sand content: 50 g/m³
- pH values: 6 to 8
- Liquid Temp. up to 35 °C
- Material:
1. Impellers/Diffusers – SUS 304
2. Shaft -SUS304
WS-01 series
Product Features
- 100% SUS 304 stainless steel made
- Superior hydraulics, reliability and pumping efficiency
- Longer lifetime
- Strong, stainless-steel quality
- Sand resistance
Applications
- Irrigation/ water supply
- Groundwater intake/ water supply
- Dewatering (pasturage, sump, pond, and mining drainage, etc.)
- Fountains
- Pressure boosting
Performance Curve
50Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | LENGTH | WEIGHT | Required Power | ||
| (inch) | (m) | L/min | M³/hr. | (m) | (mm) | (kg) | HP | kW | |
| WS-0109 | 1-1/4″ | 52 | 10 | 0.6 | 34 | 354 | 3.1 | 0.5 | 0.37 |
| WS-0114 | 1-1/4″ | 79 | 10 | 0.6 | 50 | 459 | 4 | 0.5 | 0.37 |
| WS-0118 | 1-1/4″ | 102 | 10 | 0.6 | 67 | 543 | 4.7 | 0.75 | 0.55 |
| WS-0121 | 1-1/4″ | 118 | 10 | 0.6 | 76 | 606 | 5.2 | 0.75 | 0.55 |
| WS-0128 | 1-1/4″ | 158 | 10 | 0.6 | 102 | 753 | 6.6 | 1 | 0.75 |
| WS-0136 | 1-1/4″ | 205 | 10 | 0.6 | 117 | 946 | 8.6 | 1.5 | 1.1 |
| WS-0142 | 1-1/4″ | 238 | 10 | 0.6 | 134 | 1072 | 9.8 | 1.5 | 1.1 |
60Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | LENGTH | WEIGHT | Required Power | ||
| (inch) | (m) | L/min | M³/hr. | (m) | (mm) | (kg) | HP | kW | |
| WS-0109 | 1-1/4″ | 76 | 10 | 0.6 | 56 | 354 | 3.1 | 0.5 | 0.37 |
| WS-0113 | 1-1/4″ | 108 | 10 | 0.6 | 79 | 438 | 3.8 | 0.5 | 0.37 |
| WS-0118 | 1-1/4″ | 151 | 10 | 0.6 | 109 | 543 | 4.7 | 1.0 | 0. |
| WS-0122 | 1-1/4″ | 183 | 10 | 0.6 | 135 | 627 | 5.6 | 1.0 | 0.75 |
| WS-0126 | 1-1/4″ | 220 | 10 | 0.6 | 162 | 711 | 6.4 | 1.5 | 1.1 |
| WS-0131 | 1-1/4″ | 260 | 10 | 0.6 | 173 | 816 | 7.4 | 1.5 | 1.1 |
