Technical Data
- 8″ pump
- Standard 6″ suction interconnector
- Flow: Max. 43 m³/h-50Hz / 57 m³/h-60Hz
- Head: Max. 460 m
- Max. sand content: 50 g/m³
- Liquid Temp.: 0 °C to 35 °C
- pH values: 6 to 8
- Installation depth: Max. 300m
WJ-15 series
Product Features
- 100% SUS 304 stainless steel inside out
- Resistant to sand
- Resistant to aggressive water
- Discharge casing with threaded connection. Flange optional
- Shaft made from SUS 410 stainless steel
- Suction strainer to prevent clogging
Applications
- Groundwater intake/water supply
- Municipal and industrial waters supply
- Irrigation/raw water supply
- Dewatering (construction sites, mines)
- Thermal waters, pools, and springs
- Fish farming
- Fountains
- Offshore
- Pressure boosting
Performance Curve
Specifications
50Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | MOTOR | MOTOR SIZE | ||
| inch | M | GPM | M³/hr | M | HP | kW | ||
| WJ-1502 | 3″ / 4″ | 41 | 150 | 35 | 27 | 5 | 3.7 | 6″ |
| WJ-1503 | 3″ / 4″ | 62 | 150 | 35 | 40 | 7.5 | 5.5 | 6″ |
| WJ-1504 | 3″ / 4″ | 83 | 150 | 35 | 53 | 10 | 7.5 | 6″ |
| WJ-1505 | 3″ / 4″ | 107 | 150 | 35 | 70 | 12.5 | 9.0 | 6″ |
| WJ-1506 | 3″ / 4″ | 128 | 150 | 35 | 83 | 15 | 11 | 6″ |
| WJ-1507 | 3″ / 4″ | 146 | 150 | 35 | 93 | 17.5 | 13 | 6″ |
| WJ-1508 | 3″ / 4″ | 167 | 150 | 35 | 107 | 20 | 15 | 6″ |
| WJ-1509 | 3″ / 4″ | 185 | 150 | 35 | 118 | 22.5 | 16.5 | 6″ |
| WJ-1510 | 3″ / 4″ | 206 | 150 | 35 | 134 | 25 | 18.5 | 6″ |
| WJ-1511 | 3″ / 4″ | 225 | 150 | 35 | 146 | 27.5 | 20.5 | 6″ |
| WJ-1512 | 3″ / 4″ | 250 | 150 | 35 | 164 | 30 | 22 | 6″ |
| WJ-1513 | 3″ / 4″ | 268 | 150 | 35 | 179 | 35 | 26 | 6″ |
| WJ-1514 | 3″ / 4″ | 290 | 150 | 35 | 196 | 35 | 26 | 6″ |
| WJ-1515 | 3″ / 4″ | 310 | 150 | 35 | 210 | 40 | 30 | 6″ |
| WJ-1516 | 3″ / 4″ | 333 | 150 | 35 | 223 | 40 | 30 | 6″ |
| WJ-1517 | 3″ / 4″ | 357 | 150 | 35 | 235 | 45 | 33.5 | 6″ |
| WJ-1518 | 3″ / 4″ | 380 | 150 | 35 | 253 | 50 | 37.5 | 6″ |
60Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | MOTOR | MOTOR SIZE | ||
| inch | M | GPM | M³/hr | M | HP | kW | ||
| WJ-1502 | 3″ / 4″ | 63 | 132 | 30 | 38 | 7.5 | 5.5 | 6″ |
| WJ-1503 | 3″ / 4″ | 88 | 132 | 30 | 55 | 10 | 7.5 | 6″ |
| WJ-1504 | 3″ / 4″ | 116 | 132 | 30 | 71 | 15 | 11 | 6″ |
| WJ-1505 | 3″ / 4″ | 155 | 132 | 30 | 96 | 20 | 15 | 6″ |
| WJ-1506 | 3″ / 4″ | 187 | 132 | 30 | 120 | 25 | 18.5 | 6″ |
| WJ-1507 | 3″ / 4″ | 213 | 132 | 30 | 135 | 30 | 22 | 6″ |
| WJ-1509 | 3″ / 4″ | 265 | 132 | 30 | 172 | 40 | 30 | 6″ |
| WJ-1511 | 3″ / 4″ | 318 | 132 | 30 | 212 | 50 | 37.5 | 6″ |
| WJ-1513 | 3″ / 4″ | 377 | 132 | 30 | 269 | 60 | 45 | 6″ |
