WS-05 series

Product Features

  • 100% SUS 304 stainless steel made
  • Superior hydraulics, reliability and pumping efficiency
  • Longer lifetime
  • Strong, stainless-steel quality
  • Sand resistance

Applications

  • Irrigation/ water supply
  • Groundwater intake/ water supply
  • Dewatering (pasturage, sump, pond, and mining drainage, etc.)
  • Fountains
  • Pressure boosting

down-5down-4         down-7

down-3           down-8

分類: ,

Technical Data

  • 4″ pump
  • Capacity: 05 m³/h
  • Max. sand content: 50 g/m³
  • pH values: 6 to 8
  • Liquid Temp. up to 35 °C
  • Material:
    1. Impellers/Diffusers – SUS 304
    2. Shaft -SUS304

Performance Curve

50Hz

Model DISCH TOTAL HEAD CAPACITY HEAD LENGTH WEIGHT Required Power
(inch) (m) L/min M³/hr. (m) (mm) (kg) HP kW
WS-0504 1-1/2″ 24 83 5 15 249 2.2 0.5 0.37
WS-0505 1-1/2″ 37 83 5 22 291 2.3 0.75 0.55
WS-0507 1-1/2″ 48 83 5 31 333 2.9 1 0.75
WS-0509 1-1/2″ 73 83 5 46 417 3.7 1.5 1.1
WS-0511 1-1/2″ 104 83 5 63 522 4.7 2 1.5
WS-0515 1-1/2″ 152 83 5 94 690 6.4 3 2.2
WS-0521 1-1/2″ 200 83 5 124 858 7.8 5 3.7
WS-0526 1-1/2″ 238 83 5 150 999 9.7 7.5 5.5
WS-0539 1-1/2″ 267 83 5 166 1125 11.0 7.5 5.5
WS-0547 1-1/2″ 317 83 5 200 1293 13 7.5 5.5
WS-0552 1-1/2″ 267 83 5 166 1125 11.0 7.5 5.5

60Hz

Model DISCH TOTAL HEAD CAPACITY HEAD LENGTH WEIGHT Required Power
(inch) (m) L/min M³/hr. (m) (mm) (kg) HP kW
WS-0504 1-1/2″ 36 80 4.8 25 249 2.2 0.5 0.37
WS-0505 1-1/2″ 46 80 4.8 32 270 2.4 1 0.75
WS-0507 1-1/2″ 64 80 4.8 45 312 2.8 1 0.75
WS-0509 1-1/2″ 82 80 4.8 58 354 3.2 1.5 1.1
WS-0511 1-1/2″ 100 80 4.8 71 396 3.6 2 1.5
WS-0515 1-1/2″ 136 80 4.8 97 480 4.4 3 2.2
WS-0521 1-1/2″ 190 80 4.8 136 606 5.6 4 3
WS-0526 1-1/2″ 236 80 4.8 168 711 6.6 5 3.7
WS-0539 1-1/2″ 348 80 4.8 251 984 9.2 7.5 5.5
WS-0547 1-1/2″ 424 80 4.8 300 1152 10.8 10 7.5
WS-0552 1-1/2″ 456 80 4.8 332 1257 11.8 10 7.5
