Technical Data
- 8″ pump
- Standard 6″ suction interconnector
- Flow: Max. 43 m³/h-50Hz / 57 m³/h-60Hz
- Head: Max. 460 m
- Max. sand content: 50 g/m³
- Liquid Temp.: 0 °C to 35 °C
- pH values: 6 to 8
- Installation depth: Max. 300m
WJ-20 series
Product Features
- 100% SUS 304 stainless steel inside out
- Resistant to sand
- Resistant to aggressive water
- Discharge casing with threaded connection. Flange optional
- Shaft made from SUS 410 stainless steel
- Suction strainer to prevent clogging
Applications
- Groundwater intake/water supply
- Municipal and industrial waters supply
- Irrigation/raw water supply
- Dewatering (construction sites, mines)
- Thermal waters, pools, and springs
- Fish farming
- Fountains
- Offshore
- Pressure boosting
Performance Curve
Specifications
50Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | MOTOR | MOTOR SIZE | ||
| inch | M | GPM | M³/hr | M | HP | kW | ||
| WJ-2001 | 3″ / 4″ | 21 | 190 | 44 | 13 | 5 | 3.7 | 6″ |
| WJ-2002 | 3″ / 4″ | 42 | 190 | 44 | 25 | 7.5 | 5.5 | 6″ |
| WJ-2003 | 3″ / 4″ | 52 | 190 | 44 | 40 | 10 | 7.5 | 6″ |
| WJ-2004 | 3″ / 4″ | 88 | 190 | 44 | 58 | 15 | 11 | 6″ |
| WJ-2005 | 3″ / 4″ | 106 | 190 | 44 | 68 | 17.5 | 13 | 6″ |
| WJ-2006 | 3″ / 4″ | 132 | 190 | 44 | 85 | 20 | 15 | 6″ |
| WJ-2007 | 3″ / 4″ | 167 | 190 | 44 | 101 | 25 | 18.5 | 6″ |
| WJ-2008 | 3″ / 4″ | 176 | 190 | 44 | 113 | 25 | 18.5 | 6″ |
| WJ-2009 | 3″ / 4″ | 200 | 190 | 44 | 128 | 30 | 22 | 6″ |
| WJ-2010 | 3″ / 4″ | 227 | 190 | 44 | 143 | 35 | 26 | 6″ |
| WJ-2011 | 3″ / 4″ | 248 | 190 | 44 | 158 | 40 | 30 | 6″ |
| WJ-2012 | 3″ / 4″ | 267 | 190 | 44 | 175 | 40 | 30 | 6″ |
| WJ-2013 | 3″ / 4″ | 288 | 190 | 44 | 190 | 50 | 37.5 | 6″ |
| WJ-2014 | 3″ / 4″ | 310 | 190 | 44 | 207 | 50 | 37.5 | 6″ |
| WJ-2015 | 3″ / 4″ | 334 | 190 | 44 | 223 | 50 | 37.5 | 6″ |
| WJ-2016 | 3″ / 4″ | 362 | 190 | 44 | 236 | 60 | 45 | 6″ |
| WJ-2017 | 3″ / 4″ | 383 | 190 | 44 | 253 | 60 | 45 | 6″ |
| WJ-2018 | 3″ / 4″ | 408 | 190 | 44 | 271 | 60 | 45 | 6″ |
60Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | MOTOR | MOTOR SIZE | ||
| inch | M | GPM | M³/hr | M | HP | kW | ||
| WJ-2001 | 3″ / 4″ | 35 | 60 | 264 | 20 | 7.5 | 5.5 | 6″ |
| WJ-2002 | 3″ / 4″ | 58 | 60 | 264 | 41 | 10 | 7.5 | 6″ |
| WJ-2003 | 3″ / 4″ | 102 | 60 | 264 | 62 | 20 | 15 | 6″ |
| WJ-2004 | 3″ / 4″ | 131 | 60 | 264 | 80 | 25 | 18.5 | 6″ |
| WJ-2005 | 3″ / 4″ | 166 | 60 | 264 | 105 | 30 | 22 | 6″ |
| WJ-2006 | 3″ / 4″ | 205 | 60 | 264 | 129 | 40 | 30 | 6″ |
| WJ-2008 | 3″ / 4″ | 268 | 60 | 264 | 170 | 50 | 37.5 | 6″ |
| WJ-2010 | 3″ / 4″ | 332 | 60 | 264 | 207 | 60 | 45 | 6″ |
| WJ-2012 | 3″ / 4″ | 398 | 60 | 264 | 267 | 75 | 55 | 6″ |
