Technical Data
- 6″ pump
- Capacity: 46 m³/h
- Max. sand content: 50 g/m³
- pH values: 6 to 8
- Liquid Temp. up to 35 °C
- Material:
1. Impellers/Diffusers – SUS 304
2. Shaft -SUS431QT
WS-46 series
Product Features
- 100% SUS 304 stainless steel made
- Superior hydraulics, reliability and pumping efficiency
- Longer lifetime
- Strong, stainless-steel quality
- Sand resistance
Applications
- Irrigation/ water supply
- Groundwater intake/ water supply
- Dewatering (pasturage, sump, pond, and mining drainage, etc.)
- Fountains
- Pressure boosting
Performance Curve
50Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | LENGTH | WEIGHT | Required Power | ||
| (inch) | (m) | L/min | M³/hr. | (m) | (mm) | (kg) | HP | kW | |
| WS-4602 | 4″ | 26 | 400 | 24 | 15 | 504 | 8.45 | 4 | 3 |
| WS-4603 | 4″ | 41 | 400 | 24 | 25 | 617 | 10.7 | 7.5 | 5.5 |
| WS-4605 | 4″ | 68 | 400 | 24 | 40 | 858 | 15.2 | 10 | 7.5 |
| WS-4607 | 4″ | 96 | 400 | 24 | 56 | 1084 | 19.7 | 15 | 11 |
| WS-4610 | 4″ | 138 | 400 | 24 | 81 | 1423 | 26.5 | 20 | 15 |
| WS-4612 | 4″ | 163 | 400 | 24 | 99 | 1649 | 31 | 25 | 18.5 |
| WS-4615 | 4″ | 208 | 400 | 24 | 125 | 1988 | 37.8 | 30 | 22 |
| WS-4617 | 4″ | 234 | 400 | 24 | 147 | 2214 | 42.3 | 35 | 26 |
| WS-4619 | 4″ | 260 | 400 | 24 | 155 | 2440 | 46.7 | 40 | 30 |
| WS-4622 | 4″ | 302 | 400 | 24 | 184 | 2779 | 53.3 | 50 | 37 |
| WS-4624 | 4″ | 330 | 40 | 24 | 204 | 2892 | 57.8 | 50 | 37 |
60Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | LENGTH | WEIGHT | Required Power | ||
| (inch) | (m) | L/min | M³/hr. | (m) | (mm) | (kg) | HP | kW | |
| WS-4601 | 4″ | 21 | 500 | 30 | 14 | 391 | 6.3 | 4 | 3 |
| WS-4602 | 4″ | 38 | 500 | 30 | 27 | 504 | 8.5 | 7.5 | 5.5 |
| WS-4603 | 4″ | 60 | 500 | 30 | 40 | 617 | 10.7 | 10 | 7.5 |
| WS-4604 | 4″ | 80 | 500 | 30 | 53 | 730 | 12.9 | 12.5 | 9.3 |
| WS-4605 | 4″ | 97 | 500 | 30 | 68 | 843 | 15.1 | 17.5 | 13 |
| WS-4606 | 4″ | 122 | 500 | 30 | 82 | 956 | 17.3 | 20 | 15 |
| WS-4607 | 4″ | 141 | 500 | 30 | 96 | 1069 | 19.5 | 25 | 18.5 |
| WS-4608 | 4″ | 160 | 500 | 30 | 109 | 1182 | 21.7 | 25 | 18.5 |
| WS-4609 | 4″ | 180 | 500 | 30 | 123 | 1295 | 23.9 | 30 | 22 |
| WS-4610 | 4″ | 202 | 500 | 30 | 139 | 1408 | 26.1 | 30 | 22 |
| WS-4613 | 4″ | 258 | 500 | 30 | 177 | 1747 | 33 | 40 | 30 |
| WS-4615 | 4″ | 299 | 500 | 30 | 212 | 1973 | 37.6 | 50 | 37 |
| WS-4617 | 4″ | 338 | 500 | 30 | 243 | 2199 | 42.2 | 50 | 37 |
| WS-4618 | 4″ | 355 | 500 | 30 | 257 | 2312 | 44.5 | 60 | 45 |
| WS-4620 | 4″ | 397 | 500 | 30 | 289 | 2358 | 49.1 | 60 | 45 |
| WS-4622 | 4″ | 415 | 500 | 30 | 311 | 2764 | 53.5 | 85 | 63 |
| WS-4624 | 4″ | 433 | 500 | 30 | 353 | 2990 | 57.9 | 85 | 63 |
