WK-15 series

Product Features

  • 100% SUS 304 stainless steel inside out
  • Resistant to sand
  • Resistant to aggressive water
  • Discharge casing with threaded connection. Flange optional
  • Shaft made from SUS 410 stainless steel
  • Suction strainer to prevent clogging

Applications

  • Groundwater intake/water supply
  • Municipal and industrial waters supply
  • Irrigation/raw water supply
  • Dewatering (construction sites, mines)
  • Thermal waters, pools, and springs
  • Fish farming
  • Fountains
  • Offshore
  • Pressure boosting

down-5down-4         down-7

down-3           down-8

分類: ,

Technical Data

  • 6 ” pump
  • Flow: Max. 27 m³/h-50Hz / 39 m³/h-60Hz
  • Head: Max. 450 m
  • Max. sand content: 50 g/m³
  • Liquid Temp.: 0 °C to 35 °C
  • pH values: 6 to 8
  • Installation depth: Max. 300 m

Performance Curve
WK-15-50Hz WK-15-60Hz

Specifications

50Hz

Model DISCH TOTAL HEAD CAPACITY HEAD MOTOR MOTOR SIZE
inch M GPM M³/hr M HP kW
WK-1502 2″ / 2 1/2″ / 3″ 27 100 23 18 3 2.2 4″
WK-1503 2″ / 2 1/2″ / 3″ 42 100 23 28 5 3.7 4″
WK-1504 2″ / 2 1/2″ / 3″ 59 100 23 40 7.5 5.5 4″
WK-1502 2″ / 2 1/2″ / 3″ 27 100 23 18 3 2.2 6″
WK-1503 2″ / 2 1/2″ / 3″ 42 100 23 28 5 3.7 6″
WK-1504 2″ / 2 1/2″ / 3″ 59 100 23 40 7.5 5.5 6″
WK-1505 2″ / 2 1/2″ / 3″ 74 100 23 51 10 7.5 6″
WK-1506 2″ / 2 1/2″ / 3″ 88 100 23 63 10 7.5 6″
WK-1507 2″ / 2 1/2″ / 3″ 102 100 23 73 12.5 9 6″
WK-1508 2″ / 2 1/2″ / 3″ 116 100 23 83 15 11 6″
WK-1509 2″ / 2 1/2″ / 3″ 130 100 23 93 17.5 13 6″
WK-1510 2″ / 2 1/2″ / 3″ 143 100 23 101 17.5 13 6″
WK-1511 2″ / 2 1/2″ / 3″ 154 100 23 111 20 15 6″
WK-1512 2″ / 2 1/2″ / 3″ 168 100 23 121 20 15 6″
WK-1513 2″ / 2 1/2″ / 3″ 182 100 23 131 20 15 6″
WK-1514 2″ / 2 1/2″ / 3″ 196 100 23 141 22.5 16.5 6″
WK-1515 2″ / 2 1/2″ / 3″ 210 100 23 151 22.5 16.5 6″
WK-1516 2″ / 2 1/2″ / 3″ 225 100 23 161 25 18.5 6″
WK-1517 2″ / 2 1/2″ / 3″ 240 100 23 171 25 18.5 6″
WK-1518 2″ / 2 1/2″ / 3″ 257 100 23 183 27.5 20.5 6″
WK-1519 2″ / 2 1/2″ / 3″ 272 100 23 193 30 22 6″
WK-1520 2″ / 2 1/2″ / 3″ 286 100 23 203 30 22 6″
WK-1523 2″ / 2 1/2″ / 3″ 340 100 23 237 35 26 6″
WK-1524 2″ / 2 1/2″ / 3″ 355 100 23 247 35 26 6″
WK-1525 2″ / 2 1/2″ / 3″ 369 100 23 257 35 26 6″
WK-1527 2″ / 2 1/2″ / 3″ 395 100 23 277 40 30 6″

60Hz

Model DISCH TOTAL HEAD CAPACITY HEAD MOTOR MOTOR SIZE
inch M GPM M³/hr M HP kW
WK-1501 2″ / 2 1/2″ / 3″ 21 132 30 16 3 2.2 4″
WK-1502 2″ / 2 1/2″ / 3″ 44 132 30 21 7.5 5.5 4″
WK-1502 2″ / 2 1/2″ / 3″ 44 132 30 21 7.5 5.5 6″
WK-1503 2″ / 2 1/2″ / 3″ 68 132 30 50 10 7.5 6″
WK-1505 2″ / 2 1/2″ / 3″ 114 132 30 87 15 11 6″
WK-1506 2″ / 2 1/2″ / 3″ 135 132 30 100 20 15 6″
WK-1507 2″ / 2 1/2″ / 3″ 157 132 30 116 20 15 6″
WK-1508 2″ / 2 1/2″ / 3″ 179 132 30 132 25 18.5 6″
WK-1509 2″ / 2 1/2″ / 3″ 202 132 30 150 30 22 6″
WK-1510 2″ / 2 1/2″ / 3″ 238 132 30 163 30 22 6″
WK-1511 2″ / 2 1/2″ / 3″ 245 132 30 177 30 22 6″
WK-1513 2″ / 2 1/2″ / 3″ 293 132 30 217 40 30 6″
WK-1514 2″ / 2 1/2″ / 3″ 313 132 30 232 40 30 6″
WK-1517 2″ / 2 1/2″ / 3″ 377 132 30 281 50 37 6″
WK-1518 2″ / 2 1/2″ / 3″ 399 132 30 296 50 37 6″
WK-1520 2″ / 2 1/2″ / 3″ 443 132 30 335 60 45 6″
WK-1521 2″ / 2 1/2″ / 3″ 464 132 30 350 60 45 6″
