WS-60 series

Product Features

  • 100% SUS 304 stainless steel made
  • Superior hydraulics, reliability and pumping efficiency
  • Longer lifetime
  • Strong, stainless-steel quality
  • Sand resistance

Applications

  • Irrigation/ water supply
  • Groundwater intake/ water supply
  • Dewatering (pasturage, sump, pond, and mining drainage, etc.)
  • Fountains
  • Pressure boosting

down-5down-4         down-7

down-3           down-8

分類: ,

Technical Data

  • 6″ pump
  • Capacity: 60 m³/h
  • Max. sand content: 50 g/m³
  • pH values: 6 to 8
  • Liquid Temp. up to 35 °C
  • Material:
    1. Impellers/Diffusers – SUS 304
    2. Shaft -SUS431QT

Performance Curve

50Hz

Model DISCH TOTAL HEAD CAPACITY HEAD LENGTH WEIGHT Required Power
(inch) (m) L/min M³/hr. (m) (mm) (kg) HP kW
WS-6001 4″ 15.4 1000 60 6 391 6.4 3 2.2
WS-6002 4″ 27 1000 60 13 504 8.7 5.5 4
WS-6003 4″ 41 1000 60 20 617 11 7.5 5.5
WS-6004 4″ 55 1000 60 29 745 13.2 10 7.5
WS-6005 4″ 70 1000 60 38 873 15.4 12.5 11
WS-6006 4″ 81 1000 60 45 971 17.8 15 11
WS-6007 4″ 97 1000 60 52 1084 20.1 17.5 13
WS-6008 4″ 110 1000 60 58 1197 22.3 20 15
WS-6009 4″ 125 1000 60 66 1314 24.6 25 18.5
WS-6010 4″ 140 1000 60 74 1423 26.9 25 18.5
WS-6011 4″ 154 1000 60 81 1536 29.2 30 22
WS-6012 4″ 168 1000 60 88 1762 31.4 30 22
WS-6013 4″ 180 1000 60 95 1649 33.7 35 26
WS-6014 4″ 194 1000 60 102 1878 36 35 26
WS-6015 4″ 210 1000 60 110 1988 38.2 35 26
WS-6016 4″ 222 1000 60 118 2098 40.4 40 30
WS-6017 4″ 240 1000 60 126 2208 42.6 50 37
WS-6018 4″ 251 1000 60 134 2318 44.8 50 37
WS-6020 4″ 288 1000 60 150 2538 49.2 50 37

60Hz

Model DISCH TOTAL HEAD CAPACITY HEAD LENGTH WEIGHT Required Power
(inch) (m) L/min M³/hr. (m) (mm) (kg) HP kW
WS-6001 4″ 21 1000 60 10 391 6.4 5 3.7
WS-6002 4″ 41 1000 60 24 504 8.7 7.5 5.5
WS-6003 4″ 60 1000 60 38 617 11 12.5 9.3
WS-6004 4″ 80 1000 60 51 730 13.3 15 11
WS-6005 4″ 101 1000 60 66 843 15.6 17.5 13
WS-6006 4″ 121 1000 60 78 956 17.9 25 18.5
WS-6007 4″ 139 1000 60 91 1069 20.2 25 18.5
WS-6008 4″ 160 1000 60 106 1182 22.5 30 22
WS-6009 4″ 180 1000 60 117 1295 24.8 35 26
WS-6010 4″ 196 1000 60 129 1408 27.1 35 26
WS-6011 4″ 220 1000 60 146 1521 29.4 40 30
WS-6012 4″ 240 1000 60 164 1634 31.7 50 37
WS-6013 4″ 262 1000 60 174 1747 34 50 37
WS-6014 4″ 278 1000 60 187 1860 36.3 50 37
WS-6015 4″ 305 1000 60 200 1973 38.6 60 45
WS-6016 4″ 321 1000 60 212 2086 40.9 60 45
WS-6017 4″ 344 1000 60 223 2199 43.2 60 45
WS-6018 4″ 353 1000 60 239 2312 45.5 75 55
