Technical Data
- 4″ pump
- Capacity: 14 m³/h
- Max. sand content: 50 g/m³
- pH values: 6 to 8
- Liquid Temp. up to 35 °C
- Material:
1. Impellers/Diffusers – SUS 304
2. Shaft -SUS304
WS-14 series
Product Features
- 100% SUS 304 stainless steel made
- Superior hydraulics, reliability and pumping efficiency
- Longer lifetime
- Strong, stainless-steel quality
- Sand resistance
Applications
- Irrigation/ water supply
- Groundwater intake/ water supply
- Dewatering (pasturage, sump, pond, and mining drainage, etc.)
- Fountains
- Pressure boosting
Performance Curve
50Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | LENGTH | WEIGHT | Required Power | ||
| (inch) | (m) | L/min | M³/hr. | (m) | (mm) | (kg) | HP | kW | |
| WS-1405 | 2″ | 32 | 200 | 12 | 21 | 503 | 5.4 | 2 | 1.5 |
| WS-1407 | 2″ | 45 | 200 | 12 | 31 | 633 | 6.8 | 3 | 2.2 |
| WS-1410 | 2″ | 65 | 200 | 12 | 44 | 828 | 7.4 | 5 | 3 |
| WS-1413 | 2″ | 84 | 200 | 12 | 57 | 1023 | 8.9 | 5.5 | 4 |
| WS-1418 | 2″ | 117 | 200 | 12 | 80 | 1348 | 13.7 | 7.5 | 5.5 |
| WS-1425 | 2″ | 163 | 200 | 12 | 109 | 1803 | 17.9 | 10 | 7.5 |
60Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | LENGTH | WEIGHT | Required Power | ||
| (inch) | (m) | L/min | M³/hr. | (m) | (mm) | (kg) | HP | kW | |
| WS-1403 | 2″ | 29 | 200 | 12 | 22 | 373 | 4.7 | 2 | 1.5 |
| WS-1405 | 2″ | 48 | 200 | 12 | 37 | 503 | 5.8 | 3 | 2.2 |
| WS-1408 | 2″ | 77 | 200 | 12 | 59 | 698 | 7.7 | 5 | 3.7 |
| WS-1412 | 2″ | 115 | 200 | 12 | 88 | 958 | 10.1 | 7.5 | 5.5 |
| WS-1416 | 2″ | 154 | 200 | 12 | 117 | 1218 | 12.5 | 10 | 7.5 |
