Technical Data
- 8″ pump
- Standard 6″ suction interconnector
- Flow: Max. 43 m³/h-50Hz / 57 m³/h-60Hz
- Head: Max. 460 m
- Max. sand content: 50 g/m³
- Liquid Temp.: 0 °C to 35 °C
- pH values: 6 to 8
- Installation depth: Max. 300m
WJ-08 series
Product Features
- 100% SUS 304 stainless steel inside out
- Resistant to sand
- Resistant to aggressive water
- Discharge casing with threaded connection. Flange optional
- Shaft made from SUS 410 stainless steel
- Suction strainer to prevent clogging
Applications
- Groundwater intake/water supply
- Municipal and industrial waters supply
- Irrigation/raw water supply
- Dewatering (construction sites, mines)
- Thermal waters, pools, and springs
- Fish farming
- Fountains
- Offshore
- Pressure boosting
Performance Curve
Specifications
50Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | MOTOR | MOTOR SIZE | ||
| inch | M | GPM | M³/hr | M | HP | kW | ||
| WJ-0803 | 3″ / 4″ | 54 | 100 | 23 | 34 | 5 | 3.7 | 6″ |
| WJ-0805 | 3″ / 4″ | 90 | 100 | 23 | 60 | 7.5 | 5.5 | 6″ |
| WJ-0807 | 3″ / 4″ | 123 | 100 | 23 | 77 | 10 | 7.5 | 6″ |
| WJ-0809 | 3″ / 4″ | 160 | 100 | 23 | 104 | 15 | 11 | 6″ |
| WJ-0813 | 3″ / 4″ | 225 | 100 | 23 | 145 | 20 | 15 | 6″ |
| WJ-0816 | 3″ / 4″ | 285 | 100 | 23 | 180 | 25 | 18.5 | 6″ |
| WJ-0819 | 3″ / 4″ | 337 | 100 | 23 | 217 | 30 | 22 | 6″ |
| WJ-0823 | 3″ / 4″ | 400 | 100 | 23 | 270 | 40 | 30 | 6″ |
60Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | MOTOR | MOTOR SIZE | ||
| inch | M | GPM | M³/hr | M | HP | kW | ||
| WJ-0803 | 3″ /4″ | 80 | 132 | 30 | 51 | 7.5 | 5.5 | 6″ |
| WJ-0804 | 3″ /4″ | 108 | 132 | 30 | 69 | 10.0 | 7.5 | 6″ |
| WJ-0806 | 3″ /4″ | 159 | 132 | 30 | 99 | 15.0 | 11.0 | 6″ |
| WJ-0808 | 3″ /4″ | 212 | 132 | 30 | 130 | 20 | 15.0 | 6″ |
| WJ-0809 | 3″ /4″ | 237 | 132 | 30 | 150 | 25.0 | 18.5 | 6″ |
| WJ-0811 | 3″ /4″ | 290 | 132 | 30 | 186 | 30.0 | 22.0 | 6″ |
| WJ-0816 | 3″ /4″ | 368 | 132 | 30 | 242 | 40 | 30.0 | 6″ |
| WJ-0819 | 3″ /4″ | 468 | 132 | 30 | 325 | 50 | 37.5 | 6″ |
