Technical Data
- 4″ pump
- Capacity: 02 m³/h
- Max. sand content: 50 g/m³
- pH values: 6 to 8
- Liquid Temp. up to 35 °C
- Material:
1. Impellers/Diffusers – SUS 304
2. Shaft -SUS304
WS-02 series
Product Features
- 100% SUS 304 stainless steel made
- Superior hydraulics, reliability and pumping efficiency
- Longer lifetime
- Strong, stainless-steel quality
- Sand resistance
Applications
- Irrigation/ water supply
- Groundwater intake/ water supply
- Dewatering (pasturage, sump, pond, and mining drainage, etc.)
- Fountains
- Pressure boosting
Performance Curve
50Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | LENGTH | WEIGHT | Required Power | ||
| (inch) | (m) | L/min | M³/hr. | (m) | (mm) | (kg) | HP | kW | |
| WS-0209 | 1-1/4″ | 53 | 20 | 1.2 | 32 | 354 | 3.2 | 0.5 | 0.37 |
| WS-0213 | 1-1/4″ | 77 | 20 | 1.2 | 48 | 438 | 4 | 0.75 | 0.55 |
| WS-0218 | 1-1/4″ | 104 | 20 | 1.2 | 67 | 543 | 5.1 | 1 | 0.75 |
| WS-0223 | 1-1/4″ | 136 | 20 | 1.2 | 86 | 648 | 6.2 | 1.5 | 1.1 |
| WS-0228 | 1-1/4″ | 166 | 20 | 1.2 | 106 | 753 | 7.0 | 2 | 1.5 |
| WS-0233 | 1-1/4″ | 195 | 20 | 1.2 | 121 | 858 | 8.1 | 2 | 1.5 |
| WS-0240 | 1-1/4″ | 235 | 20 | 1.2 | 150 | 1041 | 10.4 | 3 | 2.2 |
| WS-0248 | 1-1/4″ | 280 | 20 | 1.2 | 176 | 1209 | 12.1 | 3 | 2.2 |
60Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | LENGTH | WEIGHT | Required Power | ||
| (inch) | (m) | L/min | M³/hr. | (m) | (mm) | (kg) | HP | kW | |
| WS-0206 | 1-1/4″ | 51 | 30 | 1.8 | 51 | 291 | 2.6 | 0.5 | 0.37 |
| WS-0209 | 1-1/4″ | 77 | 30 | 1.8 | 77 | 354 | 3.2 | 0.5 | 0.37 |
| WS-0212 | 1-1/4″ | 103 | 30 | 1.8 | 103 | 417 | 3.8 | 1.0 | 0.75 |
| WS-0215 | 1-1/4″ | 128 | 30 | 1.8 | 128 | 480 | 4.4 | 1.0 | 0.75 |
| WS-0221 | 1-1/4″ | 179 | 30 | 1.8 | 179 | 606 | 5.7 | 1.5 | 1.1 |
| WS-0227 | 1-1/4″ | 229 | 30 | 1.8 | 229 | 732 | 7 | 2.0 | 1.5 |
| WS-0234 | 1-1/4″ | 287 | 30 | 1.8 | 287 | 879 | 8.3 | 3.0 | 2.2 |
