Technical Data
- 8″ pump
- Standard 6″ suction interconnector
- Flow: Max. 43 m³/h-50Hz / 57 m³/h-60Hz
- Head: Max. 460 m
- Max. sand content: 50 g/m³
- Liquid Temp.: 0 °C to 35 °C
- pH values: 6 to 8
- Installation depth: Max. 300m
WJ-12 series
Product Features
- 100% SUS 304 stainless steel inside out
- Resistant to sand
- Resistant to aggressive water
- Discharge casing with threaded connection. Flange optional
- Shaft made from SUS 410 stainless steel
- Suction strainer to prevent clogging
Applications
- Groundwater intake/water supply
- Municipal and industrial waters supply
- Irrigation/raw water supply
- Dewatering (construction sites, mines)
- Thermal waters, pools, and springs
- Fish farming
- Fountains
- Offshore
- Pressure boosting
Performance Curve
Specifications
50Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | MOTOR | MOTOR SIZE | ||
| inch | M | GPM | M³/hr | M | HP | kW | ||
| WJ-1202 | 3″ / 4″ | 41 | 120 | 28 | 29 | 5 | 3.7 | 6″ |
| WJ-1203 | 3″ / 4″ | 62 | 120 | 28 | 43 | 7.5 | 5.5 | 6″ |
| WJ-1204 | 3″ / 4″ | 83 | 120 | 28 | 55 | 10 | 7.5 | 6″ |
| WJ-1205 | 3″ / 4″ | 101 | 120 | 28 | 67 | 10 | 7.5 | 6″ |
| WJ-1206 | 3″ / 4″ | 122 | 120 | 28 | 83 | 15 | 11 | 6″ |
| WJ-1207 | 3″ / 4″ | 144 | 120 | 28 | 97 | 15 | 11 | 6″ |
| WJ-1208 | 3″ / 4″ | 165 | 120 | 28 | 112 | 17.5 | 13 | 6″ |
| WJ-1209 | 3″ / 4″ | 187 | 120 | 28 | 127 | 20 | 15 | 6″ |
| WJ-1210 | 3″ / 4″ | 208 | 120 | 28 | 138 | 22.5 | 16.5 | 6″ |
| WJ-1211 | 3″ / 4″ | 228 | 120 | 28 | 156 | 25 | 18.5 | 6″ |
| WJ-1212 | 3″ / 4″ | 250 | 120 | 28 | 173 | 27.5 | 20.5 | 6″ |
| WJ-1213 | 3″ / 4″ | 267 | 120 | 28 | 185 | 30 | 22 | 6″ |
| WJ-1214 | 3″ / 4″ | 288 | 120 | 28 | 197 | 30 | 22 | 6″ |
| WJ-1218 | 3″ / 4″ | 360 | 120 | 28 | 259 | 40 | 30 | 6″ |
| WJ-1223 | 3″ / 4″ | 460 | 120 | 28 | 331 | 50 | 37.5 | 6″ |
60Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | HEAD | MOTOR | MOTOR SIZE | ||
| inch | M | GPM | M³/hr | M | HP | kW | ||
| WJ-1202 | 3″ /4″ | 62 | 160 | 36 | 40 | 7.5 | 5.5 | 6″ |
| WJ-1203 | 3″ /4″ | 91 | 160 | 36 | 59 | 10 | 7.5 | 6″ |
| WJ-1204 | 3″ /4″ | 150 | 160 | 36 | 87 | 15 | 11 | 6″ |
| WJ-1205 | 3″ /4″ | 152 | 160 | 36 | 102 | 20 | 15 | 6″ |
| WJ-1207 | 3″ /4″ | 211 | 160 | 36 | 142 | 25 | 18.5 | 6″ |
| WJ-1208 | 3″ /4″ | 238 | 160 | 36 | 160 | 30 | 22 | 6″ |
| WJ-1211 | 3″ /4″ | 312 | 160 | 36 | 218 | 40 | 30 | 6″ |
| WJ-1213 | 3″ /4″ | 363 | 160 | 36 | 257 | 50 | 37.5 | 6″ |
