Technical Data
- 14″ pump
- Standard 8″ suction interconnector
- Flow: 177 m³/h-50Hz / 195 m³/h-60Hz
- Head: Max. 260m
- Max. sand content: 50 g/m³
- Liquid Temp.: 0°C to 35 °C
- pH values: 6 to 8
- Installation depth: Max. 150 m
WM-14 series
Product Features
- 100% SUS 304 stainless steel inside out
- Resistant to sand
- Resistant to aggressive water
- Discharge casing with threaded connection. Flange optional
- Shaft made from SUS 410 stainless steel
- Suction strainer to prevent clogging
Applications
- Groundwater intake/water supply
- Municipal and industrial waters supply
- Irrigation/raw water supply
- Dewatering (construction sites, mines)
- Thermal waters, pools, and springs
- Fish farming
- Fountains
- Offshore
- Pressure boosting
Performance Curve
Specifications
50Hz
| Model | DISCH | TOTAL HEAD |
CAPACITY | HEAD | MOTOR | ||
| inch | M | GPM | M³/hr | M | HP | kW | |
| WM-1401 | 6″10K Flange | 43 | 780 | 177 | 28 | 25 | 18.5 |
| WM-1402 | 6″10K Flange | 86 | 780 | 177 | 56 | 50 | 37.5 |
| WM-1403 | 6″10K Flange | 134 | 780 | 177 | 87 | 80 | 60 |
| WM-1404 | 6″10K Flange | 178 | 780 | 177 | 113 | 120 | 90 |
| WM-1405 | 6″10K Flange | 225 | 780 | 177 | 142 | 140 | 105 |
| WM-1406 | 6″10K Flange | 266 | 780 | 177 | 174 | 160 | 120 |
60Hz
| Model | DISCH | TOTAL HEAD |
CAPACITY | HEAD | MOTOR | ||
| inch | M | GPM | M³/hr | M | HP | kW | |
| WM-1401 | 6″10K Flange | 65 | 900 | 204 | 40 | 50 | 37.5 |
| WM-1402 | 6″10K Flange | 133 | 900 | 204 | 87 | 100 | 75 |
| WM-1403 | 6″10K Flange | 160 | 900 | 204 | 107 | 120 | 90 |
