Technical Data
- 4″ pump
- Capacity: 14 m³/h / 60 GPM
- Max. sand content: 50g/m³
- pH values: 6 to 8
- Liquid Temp. up to 35°C
- Material:
- Impellers – POM (WP05~35) / PC/GF(WP40~)
- Diffusers – PC/GF
WP-60 series
Product Features
- Floating impeller design for sand resistance and reducessand blocking
- Built-in check valve to prevent back flow
- SUS 304 polished stainless steel shell
- Shafts are made from hex 304 stainless steel bar material
- Built-in SUS 304 stainless steel strainer
Applications
- Residential potable water supply from deep wells
- Municipal and industrial water supply
- Irrigation and other agricultural applications
- Firefighting systems
- Pressure boosting in high-rise buildings and other applications
Performance Curve
50Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | M³/hr | HEAD | MOTOR | kW |
| inch | M | GPM | M | HP | |||
| WP-6007 | 1-1/4″/1-1/2″/2″ | 46 | 60 | 14 | 23 | 2 | 1.5 |
| WP-6010 | 1-1/4″/1-1/2″/2″ | 65 | 60 | 14 | 33 | 3 | 2.2 |
| WP-6014 | 1-1/4″/1-1/2″/2″ | 91 | 60 | 14 | 50 | 4 | 3 |
| WP-6017 | 1-1/4″/1-1/2″/2″ | 108 | 60 | 14 | 57 | 5 | 3.7 |
| WP-6019 | 1-1/4″/1-1/2″/2″ | 126 | 60 | 14 | 71 | 5.5 | 4 |
| WP-6026 | 1-1/4″/1-1/2″/2″ | 167 | 60 | 14 | 90 | 7.5 | 5.5 |
60Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | M³/hr | HEAD | MOTOR | kW |
| inch | M | GPM | M | HP | |||
| WP-6004 | 1-1/4″/1-1/2″/2″ | 38 | 60 | 14 | 25 | 1.5 | 1.1 |
| WP-6005 | 1-1/4″/1-1/2″/2″ | 45 | 60 | 14 | 28 | 2 | 1.5 |
| WP-6007 | 1-1/4″/1-1/2″/2″ | 64 | 60 | 14 | 39 | 3 | 2.2 |
| WP-6009 | 1-1/4″/1-1/2″/2″ | 84 | 60 | 14 | 54 | 4 | 3 |
| WP-6011 | 1-1/4″/1-1/2″/2″ | 101 | 60 | 14 | 65 | 5 | 3.7 |
| WP-6012 | 1-1/4″/1-1/2″/2″ | 112 | 60 | 14 | 73 | 5.5 | 4 |
| WP-6017 | 1-1/4″/1-1/2″/2″ | 158 | 60 | 14 | 101 | 7.5 | 5.5 |
