Technical Data
- 4″ pump
- Capacity: 6 m³/h / 25 GPM
- Max. sand content: 50g/m³
- pH values: 6 to 8
- Liquid Temp. up to 35°C
- Material:
- Impellers – POM (WP05~35) / PC/GF(WP40~)
- Diffusers – PC/GF
WP-25 series
Product Features
- Floating impeller design for sand resistance and reducessand blocking
- Built-in check valve to prevent back flow
- SUS 304 polished stainless steel shell
- Shafts are made from hex 304 stainless steel bar material
- Built-in SUS 304 stainless steel strainer
Applications
- Residential potable water supply from deep wells
- Municipal and industrial water supply
- Irrigation and other agricultural applications
- Firefighting systems
- Pressure boosting in high-rise buildings and other applications
Performance Curve
50Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | M³/hr | HEAD | MOTOR | kW |
| inch | M | GPM | M | HP | |||
| WP-2506 | 1-1/4″/1-1/2″/2″ | 44 | 25 | 6 | 17 | 0.5 | 0.37 |
| WP-2509 | 1-1/4″/1-1/2″/2″ | 66 | 25 | 6 | 24 | 1 | 0.75 |
| WP-2512 | 1-1/4″/1-1/2″/2″ | 88 | 25 | 6 | 33 | 1.5 | 1.1 |
| WP-2515 | 1-1/4″/1-1/2″/2″ | 112 | 25 | 6 | 45 | 2 | 1.5 |
| WP-2522 | 1-1/4″/1-1/2″/2″ | 162 | 25 | 6 | 64 | 3 | 2.2 |
| WP-2530 | 1-1/4″/1-1/2″/2″ | 222 | 25 | 6 | 90 | 4 | 3 |
| WP-2538 | 1-1/4″/1-1/2″/2″ | 275 | 25 | 6 | 101 | 5 | 3.7 |
| WP-2540 | 1-1/4″/1-1/2″/2″ | 300 | 25 | 6 | 121 | 5.5 | 4 |
60Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | M³/hr | HEAD | MOTOR | kW |
| inch | M | GPM | M | HP | |||
| WP-2504 | 1-1/4″/1-1/2″/2″” | 43 | 25 | 6 | 23 | 0.5 | 0.37 |
| WP-2507 | 1-1/4″/1-1/2″/2″ | 73 | 25 | 6 | 38 | 1 | 0.75 |
| WP-2510 | 1-1/4″/1-1/2″/2″ | 108 | 25 | 6 | 60 | 1.5 | 1.1 |
| WP-2512 | 1-1/4″/1-1/2″/2″ | 127 | 25 | 6 | 68 | 2 | 1.5 |
| WP-2517 | 1-1/4″/1-1/2″/2″ | 178 | 25 | 6 | 90 | 3 | 2.2 |
| WP-2520 | 1-1/4″/1-1/2″/2″ | 215 | 25 | 6 | 122 | 4 | 3 |
| WP-2526 | 1-1/4″/1-1/2″/2″ | 271 | 25 | 6 | 155 | 5 | 3.7 |
| WP-2530 | 1-1/4″/1-1/2″/2″ | 320 | 25 | 6 | 190 | 5.5 | 4 |
