Technical Data
- 8″ or 10″ pump
- Standard 8″ suction interconnector
- Flow: 59 m³/h-50Hz / 75 m³/h-60Hz
- Head: Max. 280 m
- Max. sand content: 50 g/m³
- Liquid Temp.: 0 °C to 35 °C
- pH values: 6 to 8
- Installation depth: Max. 200m
WM-08 series
Product Features
- 100% SUS 304 stainless steel inside out
- Resistant to sand
- Resistant to aggressive water
- Discharge casing with threaded connection. Flange optional
- Shaft made from SUS 410 stainless steel
- Suction strainer to prevent clogging
Applications
- Groundwater intake/water supply
- Municipal and industrial waters supply
- Irrigation/raw water supply
- Dewatering (construction sites, mines)
- Thermal waters, pools, and springs
- Fish farming
- Fountains
- Offshore
- Pressure boosting
Performance Curve
Specifications
50Hz
| Model | DISCH | TOTAL HEAD |
CAPACITY | HEAD | LENGTH | MOTOR | ||
| inch | M | GPM | M³/hr | M | mm | HP | kW | |
| 8″ | WM-0801 | 4″ | 25 | 260 | 59 | 16 | 18 | 10 |
| 8″ | WM-0802 | 4″ | 48 | 260 | 59 | 32 | 25 | 15 |
| 8″ | WM-0803 | 4″ | 73 | 260 | 59 | 48 | 33 | 20 |
| 8″ | WM-0804 | 4″ | 95 | 260 | 59 | 64 | 40 | 25 |
| 8″ | WM-0805 | 4″ | 118 | 260 | 59 | 78 | 47 | 30 |
| 8″ | WM-0806 | 4″ | 143 | 260 | 59 | 94 | 54 | 40 |
| 10″ | WM-0807 | 4″ | 166 | 260 | 59 | 109 | 64 | 45 |
| 10″ | WM-0808 | 4″ | 191 | 260 | 59 | 126 | 71 | 55 |
| 10″ | WM-0809 | 4″ | 214 | 260 | 59 | 142 | 78 | 60 |
| 10″ | WM-0810 | 4″ | 237 | 260 | 59 | 157 | 85 | 70 |
| 10″ | WM-0811 | 4″ | 262 | 260 | 59 | 170 | 93 | 75 |
| 10″ | WM-0812 | 4″ | 283 | 260 | 59 | 185 | 100 | 75 |
60Hz
| Model | DISCH | TOTAL HEAD |
CAPACITY | HEAD | LENGTH | MOTOR | ||
| inch | M | GPM | M³/hr | M | mm | HP | kW | |
| 8″ | WM-0801 | 4″ | 23 | 330 | 75 | 13 | 5 | 4 |
| 8″ | WM-0802 | 4″ | 54 | 330 | 75 | 34 | 15 | 11 |
| 8″ | WM-0803 | 4″ | 75 | 330 | 75 | 48 | 20 | 15 |
| 8″ | WM-0804 | 4″ | 125 | 330 | 75 | 77 | 35 | 26 |
