Technical Data
50 Hz version:
Max Blow – 306 m³/h / +200~+340 mbar
Max Vacuum – 306 m³/h / -180~-270 mbar
60 Hz version:
Max Blow – 372 m³/h / +200~+330 mbar
Max Vacuum – 372 m³/h / -220~-320 mbar
CE series
Product Features
- CE Norm: 89/336, 73/23, EN60204-1, EN50081-2, EN50082-2
- Insulation Class: F (155°C)
- Ambient Temp.: 30°C
- Degree of Protection: IP 54 (IP 55 is optional)
- Mounting: Vertical / horizontal
- Voltage Tolerance: ±10% of nominal U
Applications
- Pneumatic air tube systems
- Pneumatic conveying systems
- Vacuum dealing systems
- Vacuum transport systems
- Drying systems
- Bottle-filling stations
- Printing machines
- Dental equipment
Performance Curve
50Hz
| Model | Phase | Maximum performance when used as Blower | Maximum performance when used as Vacuum | Motor ratings | Noise Level dB(A) |
Weight | |||||
| Rated output | Voltage | Current when used as Blower | Current when used as Vacuum | ||||||||
| m³/min | mbar | m³/min | mbar | kW | V | Amps | Amps | kg | |||
| CE-5T1 | 3 | 5.1 | +220 | 5.1 | -230 | 2.20 | 200-240 / 345-416 | 10.8-10.9 / 6.0-6.1 | 11.6-9.9 / 5.6-5.8 | 76 | 36 |
| CE-5T2 | 3 | 5.1 | +200 | 5.1 | -180 | 2.20 | 200-240 / 345-416 | 9.0-9.9 / 5.3-5.8 | 8.0-9.4 / 4.5-5.3 | 76 | 36 |
| CE-5T3 | 3 | 5.1 | +280 | 5.1 | -250 | 3.00 | 200-240 / 345-416 | 13.1-13.6 / 7.4-7.7 | 11.1-12.4 / 6.3-7.0 | 76 | 38.4 |
| CE-5T4 | 3 | 5.1 | +340 | 5.1 | -270 | 4.00 | 200-240 / 345-416 | 14.7-14.8 / 8.5-8.4 | 11.5-12.5 / 6.7-7.2 | 76 | 41.5 |
| CE-5S1 | 1 | 5.1 | +200 | 5.1 | -200 | 2.20 | 230 | 14.9 | 14.7 | 76 | 42 |
| CE-6T1 | 3 | 6.2 | +200 | 6.2 | -220 | 2.55 | 208-275 / 380-480 | 11.3-10.6 / 6.4-5.9 | 11.2-10.1 / 6.0-5.7 | 78 | 36 |
| CE-6T2 | 3 | 6.2 | +255 | 6.2 | -230 | 2.55 | 208-275 / 380-480 | 12.2-10.9 / 6.6-6.2 | 10.2-9.8 / 5.6-5.5 | 78 | 36 |
60Hz
| Model | Phase | Maximum performance when used as Blower | Maximum performance when used as Vacuum | Motor ratings | Noise Level dB(A) |
Weight | |||||
| Rated output | Voltage | Current when used as Blower | Current when used as Vacuum | ||||||||
| m³/min | mbar | m³/min | mbar | kW | V | Amps | Amps | kg | |||
| CE-6T1 | 3 | 6.2 | +200 | 6.2 | -220 | 2.55 | 208-275 / 380-480 | 11.3-10.6 / 6.4-5.9 | 11.2-10.1 / 6.0-5.7 | 78 | 36 |
| CE-6T2 | 3 | 6.2 | +255 | 6.2 | -230 | 2.55 | 208-275 / 380-480 | 12.2-10.9 / 6.6-6.2 | 10.2-9.8 / 5.6-5.5 | 78 | 36 |
| CE-6T3 | 3 | 6.2 | +270 | 6.2 | -270 | 3.45 | 208-275 / 380-480 | 14.9-13.2 / 8.0-7.6 | 13.2-12.3 / 7.1-7.0 | 78 | 38.4 |
| CE-6T4 | 3 | 6.2 | +330 | 6.2 | -320 | 4.60 | 208-275 / 380-480 | 17.2-14.7 / 9.5-8.5 | 15.3-13.2 / 8.2-7.7 | 78 | 41.5 |
