Technical Data
50 Hz version:
Max Blow – 54 m³/h/ +65 mbar
Max Vacuum – 54 m³/h / -55~-60 mbar
60 Hz version:
Max Blow – 66 m³/h / +85 mbar
Max Vacuum – 66 m³/h / -75 mbar
CA series
Product Features
- CE Norm: 89/336, 73/23, EN60204-1, EN50081-2, EN50082-2
- Insulation Class: F (155°C)
- Ambient Temp.: 30°C
- Degree of Protection: IP 54 (IP 55 is optional)
- Mounting: Vertical / horizontal
- Voltage Tolerance: ±10% of nominal U
Applications
- Pneumatic air tube systems
- Pneumatic conveying systems
- Vacuum dealing systems
- Vacuum transport systems
- Drying systems
- Bottle-filling stations
- Printing machines
- Dental equipment
Performance Curve
50Hz
| Model | Phase | Maximum performance when used as Blower | Maximum performance when used as Vacuum | Motor ratings | Noise Level dB(A) |
Weight | |||||
| Rated output | Voltage | Current when used as Blower | Current when used as Vacuum | ||||||||
| m³/min | mbar | m³/min | mbar | kW | V | Amps | Amps | kg | |||
| CA-5T1 | 3 | 0.9 | +65 | 0.9 | -60 | 0.22 | 200-240 / 345-416 | 0.75-0.84 / 0.42-0.48 | 0.76-0.84 / 0.41-0.47 | 64 | 9.8 |
| CA-5S1 | 1 | 0.9 | +65 | 0.9 | -55 | 0.22 | 104-127 / 208-254 | 2.20-2.40 /1.10-1.30 | 2.17-2.40 / 1.11-1.23 | 64 | 10.5 |
60Hz
| Model | Phase | Maximum performance when used as Blower | Maximum performance when used as Vacuum | Motor ratings | Noise Level dB(A) |
Weight | |||||
| Rated output | Voltage | Current when used as Blower | Current when used as Vacuum | ||||||||
| m³/min | mbar | m³/min | mbar | kW | V | Amps | Amps | kg | |||
| CA-6T1 | 3 | 1.1 | +85 | 1.1 | -75 | 0.28 | 208-275 / 380-480 | 0.97-0.93 / 0.55-0.54 | 0.97-0.93 / 0.53-0.53 | 65 | 9.8 |
| CA-6S1 | 1 | 1.1 | +85 | 1.1 | -75 | 0.28 | 104-127 / 208-254 | 3.3-3.0 / 1.7-1.6 | 3.17-2.92 / 1.65-1.56 | 65 | 10.5 |
