Technical Data
- 6″ pump
- Capacity: 54 m³/h / 240 GPM
- Max. sand content: 50g/m³
- pH values: 6 to 8
- Liquid Temp. up to 35°C
- Material:
- Impellers – POM (WP05~35) / PC/GF(WP40~)
- Diffusers – PC/GF
WP-240 series
Product Features
- Floating impeller design for sand resistance and reducessand blocking
- Built-in check valve to prevent back flow
- SUS 304 polished stainless steel shell
- Shafts are made from hex 304 stainless steel bar material
- Built-in SUS 304 stainless steel strainer
Applications
- Residential potable water supply from deep wells
- Municipal and industrial water supply
- Irrigation and other agricultural applications
- Firefighting systems
- Pressure boosting in high-rise buildings and other applications
Performance Curve
50Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | M³/hr | HEAD | MOTOR | kW |
| inch | M | GPM | M | HP | |||
| WP-24002 | 3″ / 4″ | 28 | 240 | 54 | 18 | 7.5 | 5.5 |
| WP-24003 | 3″ / 4″ | 41 | 240 | 54 | 28 | 10 | 7.5 |
| WP-24004 | 3″ / 4″ | 55 | 240 | 54 | 38 | 12.5 | 9 |
| WP-24005 | 3″ / 4″ | 69 | 240 | 54 | 47 | 15 | 11 |
| WP-24006 | 3″ / 4″ | 81 | 240 | 54 | 51 | 17.5 | 13 |
| WP-24007 | 3″ / 4″ | 94 | 240 | 54 | 60 | 20 | 15 |
60Hz
| Model | DISCH | TOTALHEAD | CAPACITY | M³/hr | HEAD | MOTOR | kW |
| inch | M | GPM | M | HP | |||
| WP-24002 | 3″ / 4″ | 35 | 240 | 54 | 23 | 7.5 | 5.5 |
| WP-24003 | 3″ / 4″ | 59 | 240 | 54 | 33 | 10 | 7.5 |
| WP-24004 | 3″ / 4″ | 81 | 240 | 54 | 45 | 15 | 11 |
| WP-24005 | 3″ / 4″ | 100 | 240 | 54 | 60 | 20 | 15 |
| WP-24007 | 3″ / 4″ | 140 | 240 | 54 | 84 | 25 | 18.5 |
