Technical Data
- 6″ pump
- Capacity: 24 m³/h / 106 GPM
- Max. sand content: 50g/m³
- pH values: 6 to 8
- Liquid Temp. up to 35°C
- Material:
- Impellers – POM (WP05~35) / PC/GF(WP40~)
- Diffusers – PC/GF
WP-106 series
Product Features
- Floating impeller design for sand resistance and reducessand blocking
- Built-in check valve to prevent back flow
- SUS 304 polished stainless steel shell
- Shafts are made from hex 304 stainless steel bar material
- Built-in SUS 304 stainless steel strainer
Applications
- Residential potable water supply from deep wells
- Municipal and industrial water supply
- Irrigation and other agricultural applications
- Firefighting systems
- Pressure boosting in high-rise buildings and other applications
Performance Curve
50Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | M³/hr | HEAD | MOTOR | kW |
| inch | M | GPM | M | HP | |||
| WP-10603 | 3″ / 4″ | 42 | 106 | 24 | 32 | 5 | 3.7 |
| WP-10604 | 3″ / 4″ | 55 | 106 | 24 | 42 | 7.5 | 5.5 |
| WP-10605 | 3″ / 4″ | 70 | 106 | 24 | 53 | 10 | 7.5 |
| WP-10606 | 3″ / 4″ | 85 | 106 | 24 | 64 | 12.5 | 9 |
| WP-10607 | 3″ / 4″ | 97 | 106 | 24 | 73 | 15 | 11 |
| WP-10608 | 3″ / 4″ | 114 | 106 | 24 | 86 | 17.5 | 13 |
| WP-10609 | 3″ / 4″ | 127 | 106 | 24 | 95 | 20 | 15 |
60Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | M³/hr | HEAD | MOTOR | kW |
| inch | M | GPM | M | HP | |||
| WP-10602 | 3″ / 4″ | 38 | 106 | 24 | 30 | 5 | 3.7 |
| WP-10603 | 3″ / 4″ | 59 | 106 | 24 | 48 | 7.5 | 5.5 |
| WP-10604 | 3″ / 4″ | 80 | 106 | 24 | 65 | 10 | 7.5 |
| WP-10605 | 3″ / 4″ | 101 | 106 | 24 | 82 | 15 | 11 |
| WP-10606 | 3″ / 4″ | 122 | 106 | 24 | 98 | 20 | 15 |
| WP-10609 | 3″ / 4″ | 182 | 106 | 24 | 149 | 25 | 18.5 |
