Technical Data
- 10″ pump
- Standard 8″ suction interconnector
- Flow: 100 m³/h-50Hz / 128 m³/h-60Hz
- Head: Max. 377 m
- Max. sand content: 50 g/m³
- Liquid Temp.: 0 °C to 35 °C
- pH values: 6 to 8
- Installation depth: Max. 250m
WM-10 series
Product Features
- 100% SUS 304 stainless steel inside out
- Resistant to sand
- Resistant to aggressive water
- Discharge casing with threaded connection. Flange optional
- Shaft made from SUS 410 stainless steel
- Suction strainer to prevent clogging
Applications
- Groundwater intake/water supply
- Municipal and industrial waters supply
- Irrigation/raw water supply
- Dewatering (construction sites, mines)
- Thermal waters, pools, and springs
- Fish farming
- Fountains
- Offshore
- Pressure boosting
Performance Curve
Specifications
50Hz
| Model | DISCH | TOTAL HEAD |
CAPACITY | HEAD | MOTOR | ||
| inch | M | GPM | M³/hr | M | HP | kW | |
| WM-1001 | 5″ Flange | 35 | 435 | 100 | 21 | 15 | 11 |
| WM-1002 | 5″ Flange | 68 | 435 | 100 | 44 | 25 | 18.5 |
| WM-1003 | 5″ Flange | 102 | 435 | 100 | 67 | 40 | 30 |
| WM-1004 | 5″ Flange | 132 | 435 | 100 | 88 | 50 | 37.5 |
| WM-1005 | 5″ Flange | 163 | 435 | 100 | 108 | 60 | 45 |
| WM-1006 | 5″ Flange | 193 | 435 | 100 | 129 | 75 | 55 |
| WM-1007 | 5″ Flange | 227 | 435 | 100 | 149 | 85 | 64 |
| WM-1008 | 5″ Flange | 258 | 435 | 100 | 170 | 100 | 75 |
| WM-1009 | 5″ Flange | 288 | 435 | 100 | 190 | 110 | 82.5 |
| WM-1010 | 5″ Flange | 318 | 435 | 100 | 211 | 120 | 90 |
| WM-1011 | 5″ Flange | 347 | 435 | 100 | 235 | 140 | 105 |
| WM-1012 | 5″ Flange | 377 | 435 | 100 | 255 | 150 | 110 |
60Hz
| Model | DISCH | TOTAL HEAD |
CAPACITY | HEAD | MOTOR | ||
| inch | M | GPM | M³/hr | M | HP | kW | |
| WM-1001 | 5″ Flange | 40 | 550 | 125 | 21 | 15 | 11 |
| WM-1002 | 5″ Flange | 74 | 550 | 125 | 41 | 30 | 22 |
| WM-1003 | 5″ Flange | 115 | 550 | 125 | 68 | 50 | 37.5 |
| WM-1004 | 5″ Flange | 149 | 550 | 125 | 90 | 60 | 45 |
| WM-1005 | 5″ Flange | 177 | 550 | 125 | 101 | 75 | 55 |
