Technical Data
50 Hz version:
Operating pressure : 0.1 bar(1.42 psi)
Air flow : 21~27 LPM
60 Hz version:
Operating pressure : 0.1 bar(1.42 psi)
Air flow : 20~26 LPM
LA-20/25 series
Product Features
- Compact design
- Pump casing is made of aluminum
- No Lubrication Necessary
- Maintenance-free & oil-free
- Design as customer’s requirement is available
- Low noise level
- Smooth Air Flow
Applications
- Wastewater Treatment
- Inflatable Packaging Material Machines
- Koi Ponds
- Air Mattresses
- Medical Equipment
- Massage Bed and Chair Mechanisms
- Water Gardens
- Air Sampling
- Aqua Culture
- Pneumatic Massage Equipment
- Medical Application
- Septic Tanks
- Bubble Bath
- Oxygen Supply for Fish Tank
Performance Curve
50Hz
| Model | Volt | Operating pressure (bar) |
Air Flow (L/min) | Power (W) | Noise Level (dB) |
Maximum pressure | Weight (kg) |
|
| psi | bar | |||||||
| LA-20 | 110-120V/ 220-240V |
0.10 (1.42psi) | 21 | 19 | 35 | 5 | 0.35 | 2.9 |
| LA-25 | 110-120V/ 220-240V |
0.10 (1.42psi) | 27 | 23 | 37 | 4.7 | 0.33 | 2.9 |
60Hz
| Model | Volt | Operating pressure (bar) |
Air Flow (L/min) | Power (W) | Noise Level (dB) |
Maximum pressure | Weight (kg) |
|
| psi | bar | |||||||
| LA-20 | 110-120V/ 220-240V |
0.10 (1.42psi) | 20 | 17 | 36 | 4.3 | 0.3 | 2.9 |
| LA-25 | 110-120V/ 220-240V |
0.10 (1.42psi) | 26 | 21 | 38 | 5 | 0.35 | 2.9 |
