Technical Data
50 Hz version:
Operating pressure : 0.2 bar(2.84 psi)
Air flow : 151~251 LPM
60 Hz version:
Operating pressure : 0.2 bar(2.84 psi)
Air flow : 151~252 LPM
LA-150/200/250 series
Product Features
- Compact design
- Pump casing is made of aluminum
- No Lubrication Necessary
- Maintenance-free & oil-free
- Design as customer’s requirement is available
- Low noise level
- Smooth Air Flow
Applications
- Wastewater Treatment
- Inflatable Packaging Material Machines
- Koi Ponds
- Air Mattresses
- Medical Equipment
- Massage Bed and Chair Mechanisms
- Water Gardens
- Air Sampling
- Aqua Culture
- Pneumatic Massage Equipment
- Medical Application
- Septic Tanks
- Bubble Bath
- Oxygen Supply for Fish Tank
Performance Curve
50Hz
| Model | Volt | Operating pressure (bar) |
Air Flow (L/min) | Power (W) | Noise Level (dB) |
Maximum pressure | Weight (kg) |
|
| psi | bar | |||||||
| LA-150 | 110-120V/ 220-240V |
0.20 (2.84psi) | 151 | 160 | 46 | 4.97 | 0.35 | 13.6 |
| LA-200 | 110-120V/ 220-240V |
0.20(2.84psi) | 201 | 200 | 48 | 5.68 | 0.40 | 13.6 |
| LA-250 | 110-120V/ 220-240V |
0.20(2.84psi) | 251 | 261 | 50 | 7.38 | 0.52 | 13.6 |
60Hz
| Model | Volt | Operating pressure (bar) |
Air Flow (L/min) | Power (W) | Noise Level (dB) |
Maximum pressure | Weight (kg) |
|
| psi | bar | |||||||
| LA-150 | 110-120V/ 220-240V |
0.20 (2.84psi) | 151 | 201 | 51 | 5.68 | 0.40 | 13.6 |
| LA-200 | 110-120V/ 220-240V |
0.20(2.84psi) | 202 | 254 | 53 | 6.39 | 0.45 | 13.6 |
| LA-250 | 110-120V/ 220-240V |
0.20(2.84psi) | 252 | 305 | 54 | 7.10 | 0.50 | 13.6 |
