SE series
Product Features
- Single-channel impeller with long vane, thus reducing the risk of jamming or clogging, or vortex impeller with high pumping efficiency
- Double mechanical seal design in oil chamber provides strong and reliable shaft sealing
- Robust construction
- Supplied with cutter impeller for cutter pump applications
Applications
- Municipal wastewater
- Wastewater with content of fibres
- Draining of septic tanks, sumps and wastewater discharge tanks
- Drainage and groundwater
- Domestic wastewater
- Industrial wastewater
- Process and cooling water
- Emptying of tanks or reservoirs
- Emergency draining in flooded areas
Technical Data
- Max. flow rate: 3000 LPM (180 m³/h)
- Max. head: 32 m
- Max. particle size: 65 mm
- PH values: 6 to 8
- Power: 2 HP to 15 HP/ 1.5 kW to 11 kW
- Liquid Temp.: 0 °C to 40 °C/ +32 °F to +104 °F
- Degree of protection: IP 68
- Installation depth: Max. 8 m below liquid level
- Material: Motor casing – Stainless steel /
- Pump body – Cast iron
Performance Curve
Specifications
| Model |
Phase |
Output |
Outlet |
Max Flow |
Max Head |
Max. particle size |
Dimension |
Weight |
| HP |
kW |
mm |
inch |
LPM |
M |
mm |
Kg |
| SE-8020 |
1 |
2 |
1.5 |
80/100 |
3″ / 4″ |
800 |
18 |
40 |
400 x 240 x 545 |
37 |
| SE-10030 |
3 |
3 |
2.2 |
80/100 |
3″ / 4″ |
1200 |
20 |
40 |
425 x 220 x 615 |
47 |
| SE-10050 |
3 |
5 |
3.7 |
80/100 |
3″ / 4″ |
1300 |
22 |
45 |
425 x 220 x 615 |
50 |
| SE-15075 |
3 |
7.5 |
5.5 |
100/150 |
4″ / 6″ |
1900 |
24 |
50 |
485 x 300 x 735 |
104 |
| SE-150100 |
3 |
10 |
7.5 |
100/150 |
4″ / 6″ |
2300 |
27 |
65 |
485 x 300 x 840 |
114 |
| SE-150150 |
3 |
15 |
11 |
100/150 |
4″ / 6″ |
3000 |
32 |
65 |
585 x 340 x 875 |
165 |
