GA series
Product Features
- Enhanced reliability
- Efficient grinding of solids down to even smaller pieces
- Improved discharge pressure over longer distances
- Watertight cable connection is hermetically sealed, ensuring that liquid cannot penetrate through the cable into the motor
- Double mechanical seals to ensure longer lifetime
Applications
- Industrial wastewater containing fibres
- Domestic and municipal wastewater
Technical Data
- Max. flow rate: 210 LPM (12.6 m³/h)
- Max. head: 30 m
- pH values: 6 to 8
- Power: 1.5 HP to 3 HP/ 1.1 kW to 2.2 kW
- Liquid Temp.: 0 °C to 40 °C/ +32 °F to +104 °F
- Degree of protection: IP 68
- Installation depth: Max. 8 m below liquid level
- Material: Motor casing – Stainless steel / Pump body – Cast iron
Performance Curve
Specifications
| Model |
Phase |
Output |
Outlet |
Max Flow |
Max
Head |
Max. particle size |
Dimension |
Weight |
| HP |
W |
mm |
inch |
LPM |
M |
mm |
Kg |
| GA-3215 |
1 |
1.5 |
1 |
32 |
1-1/4″ |
180 |
20 |
– |
237 x 198 x 520 |
30 |
| GA-3220 |
1 |
2 |
1.5 |
32 |
1-1/4″ |
180 |
25 |
– |
237 x 198 x 540 |
32 |
| GA-3230 |
3 |
3 |
2.2 |
32 |
1-1/4″ |
210 |
28 |
– |
237 x 198 x 540 |
35 |
| GAH-3215 |
1 |
1.5 |
1 |
32 |
1-1/4″ |
100 |
30 |
– |
246 x 172 x 539 |
30 |
| GAH-3220 |
1 |
2 |
1.5 |
32 |
1-1/4″ |
160 |
30 |
– |
250 x 194 x 541 |
32 |
