RB series
Product Features
- Can be 24-hour continuous operation
- Vortex impeller with high pumping efficiency and reduce risk of jamming or clogging
- Robust construction
- Lightweight and portable
- Supplied with or without float switch
Applications
- Lawn and garden irrigation
- Sump and general drainage
- Pool emptying and fountains
- Creating streams and waterfalls in your garden pond
- Removing rain or flood water from your floors and any other locations
Technical Data
- Max. flow rate:
1. 360 LPM (22 m³/h) – 50Hz
2. 380 LPM (23 m³/h) – 60Hz
- Max. head: 11m-50Hz / 13m-60Hz
- Max. particle size: 25 mm
- pH values: 6 to 8
- Power: 1/5 HP to 1 HP/ 150 W to 750 W
- Liquid Temp.: 0 °C to 40 °C/ +32 °F to +104 °F
- Degree of protection: IP 68
- Installation depth: Max. 6m below liquid level
- Material:
- Motor casing Stainless steel
- Pump body – GF/Nylon
Performance Curve
50Hz
| Model |
Phase |
Output |
Outlet |
Max Flow |
Max Head |
Max. particle size |
Dimension |
Weight |
| HP |
W |
mm |
inch |
LPM |
M |
mm |
Kg |
| RB-4002 |
1 |
1/5 |
150 |
40 |
1-1/2″ |
230 |
6 |
25 |
236 x 164 x 352 |
7 |
| RB-4003 |
1 |
1/3 |
250 |
40 |
1-1/2″ |
270 |
7 |
25 |
236 x 164 x 352 |
8 |
| RB-5005 |
1 |
1/2 |
400 |
50 |
2″ |
320 |
9 |
25 |
236 x 164 x 372 |
8 |
| RB-5010 |
1 |
1 |
750 |
50 |
2″ |
360 |
11 |
25 |
236 x 164 x 387 |
9 |
60Hz
| Model |
Phase |
Output |
Outlet |
Max Flow |
Max Head |
Max. particle size |
Dimension |
Weight |
| HP |
W |
mm |
inch |
LPM |
M |
mm |
Kg |
| RB-4002 |
1 |
1/5 |
150 |
40 |
1-1/2″ |
240 |
7 |
25 |
236 x 164 x 352 |
7 |
| RB-4003 |
1 |
1/3 |
250 |
40 |
1-1/2″ |
280 |
9 |
25 |
236 x 164 x 352 |
8 |
| RB-5005 |
1 |
1/2 |
400 |
50 |
2″ |
330 |
11 |
25 |
236 x 164 x 372 |
8 |
| RB-5010 |
1 |
1 |
750 |
50 |
2″ |
380 |
13 |
25 |
236 x 164 x 387 |
9 |
