GB series
Product Features
- Whole pump is made of cast iron
- Enhanced reliability
- Efficient grinding of solids down to even smaller pieces
- Improved discharge pressure over longer distances
- Watertight cable connection is hermetically sealed, ensuring that liquid cannot penetrate through the cable into the motor
- Double mechanical seals to ensure longer lifetime
Applications
- Industrial wastewater containing fibres
- Domestic and municipal wastewater
Technical Data
- Max. flow rate: 360 LPM (21.6 m³/h)
- Max. head: 50 m
- pH values: 6 to 8
- Power: 2 HP to 7.5 HP/ 1.5 kW to 5.5 kW
- Liquid Temp.: 0 °C to 40 °C/ +32 °F to +104 °F
- Degree of protection: IP 68
- Installation depth: Max. 8 m below liquid level
- Material: Cast iron
Performance Curve
Specifications
| Model |
Phase |
Output |
Outlet |
Max Flow |
Max Head |
Max. particle size |
Dimension |
Weight |
| HP |
kW |
mm |
inch |
LPM |
M |
mm |
Kg |
| GB-3220 |
1 |
2 |
1.5 |
32 |
1-1/4″ |
170 |
24 |
– |
259 x 200 x 612 |
38 |
| GB-5030 |
3 |
3 |
2.2 |
50 |
2″ |
180 |
36 |
– |
239 x 200 x 620 |
42 |
| GB-6550 |
3 |
5 |
3.7 |
65 |
2-1/2″ |
340 |
42 |
– |
306 x 243 x 908 |
90 |
| GB-6575 |
3 |
7.5 |
5.5 |
65 |
2-1/2″ |
360 |
50 |
– |
306 x 243 x 908 |
80 |
