DE series
Product Features
- Vortex impeller with high pumping efficiency and reduce risk of jamming or clogging
- Robust construction
- Supplied with or without float switch
Applications
- Sump and general drainage
- Pool emptying and fountains
- Residential and light commercial sewage applications
- Creating streams and waterfalls in your garden pond
- Removing rain or flood water from your floors and any other locations
Technical Data
- Max. flow rate: 630 LPM (38 m³/h)
- Max. head: 15 m
- Max. particle size: 20 mm
- PH values: 6 to 8
- Power: 1/5 HP to 2 HP/ 150 W to 1500 W
- Liquid Temp.: 0 °C to 40 °C/ +32 °F to +104 °F
- Degree of protection: IP 68
- Installation depth: Max. 8m below liquid level
- Material: Motor casing – Stainless steel /
- Pump body – Cast iron
Performance Curve
Specifications
| Model |
Phase |
Output |
Outlet |
Max Flow |
Max
Head |
Max. particle size |
Dimension |
Weight |
| HP |
W |
mm |
inch |
LPM |
M |
mm |
Kg |
| DE-4002 |
1 |
1/5 |
150 |
40 |
1-1/2″ |
200 |
6 |
5 |
190 x 140 x 360 |
8 |
| DE-4003 |
1 |
1/3 |
250 |
40 |
1-1/2″ |
240 |
7 |
5 |
190 x 140 x 360 |
9 |
| DE-5005 |
1 |
1/2 |
400 |
50 |
2″ |
300 |
9 |
10 |
215 x 155 x 370 |
12 |
| DE-5008 |
1 |
3/4 |
550 |
50 |
2″ |
330 |
10 |
15 |
260 x 160 x 430 |
13 |
| DE-8010 |
1 |
1 |
750 |
80 |
3″ |
430 |
11 |
15 |
260 x 160 x 430 |
19 |
| DE-8020 |
1 |
2 |
1500 |
80 |
3″ |
630 |
15 |
20 |
270 x 350 x 610 |
31 |
