SA series
Product Features
- Vortex impeller with high pumping efficiency andreduce risk of jamming or clogging
- Robust construction
- Supplied with or without float switch
Applications
- Municipal wastewater
- Wastewater with content of fibres
- Draining of septic tanks, sumps and wastewater discharge tanks
- Drainage and groundwater
- Domestic wastewater
- Industrial wastewater
- Process and cooling water
- Emptying of tanks or reservoirs
- Emergency draining in flooded areas
Technical Data
- Max. flow rate: 760 LPM (46 m³/h)
- Max. head: 16 m
- Max. particle size: 40 mm
- pH values: 6 to 8
- Power: 1/5 HP to 2 HP/ 150 W to 1500 W
- Liquid Temp.: 0 °C to 40 °C/ +32 °F to +104 °F
- Degree of protection: IP 68
- Installation depth: Max. 8 m below liquid level
- Material: Motor casing – Stainless steel /
- Pump body – Cast iron
Performance Curve
Specifications
| Model |
Phase |
Output |
Outlet |
Max Flow |
Max Head |
Max. particle size |
Dimension |
Weight |
| HP |
W |
mm |
inch |
LPM |
M |
mm |
Kg |
| SA-4002 |
1 |
1/5 |
150 |
40 |
1-1/2″ |
170 |
6 |
27 |
221 x 131 x 370 |
8 |
| SA-4003 |
1 |
1/3 |
250 |
40 |
1-1/2″ |
220 |
7.5 |
27 |
221 x 135 x 370 |
9 |
| SA-5005 |
1 |
1/2 |
400 |
50 |
2″ |
360 |
8 |
35 |
232 x 137x 392 |
11 |
| SA-8008 |
1 |
3/4 |
550 |
80 |
3″ |
400 |
10 |
35 |
282 x 152 x 441 |
17 |
| SA-8010 |
1 |
1 |
750 |
80 |
3″ |
430 |
11 |
37 |
282 x 152 x 441 |
18 |
| SA-8020 |
1 |
2 |
1500 |
80 |
3″ |
760 |
16 |
40 |
311 x 200 x 547 |
31 |
