HA series
Product Features
- High quality stainless steel materials
- Robust construction
- Lightweight and portable
- The motor is cooled by the pumped liquid
- Supplied with or without float switch
Applications
- Water supply from water supply tanks or reservoirs
- 5” wells, basins and watercourses
- Sprinkler irrigation systems
- Pressure boosting with pumps inserted directly inside tank or well, to reduce suction problems and noise
- Boosting of public water and emptying of garden ponds
Technical Data
- Max. flow rate: 100 LPM (6 m³/h)
- Max. head: 60 m
- Max. particle size: 1.2 mm
- pH values: 6 to 8
- Power: 1/2 HP to 1.8 HP/ 400 W to 1350 W
- Liquid Temp.: 0 °C to 40 °C/ +32 °F to +104 °F
- Degree of protection: IP 68
- Installation depth: Max. 20 m below liquid level
- Material: Stainless steel
Performance Curve
Specifications
| Model |
Phase |
Output |
Outlet |
Max Flow |
Max Head |
Max. particle size |
Dimension |
Weight |
| HP |
W |
mm |
inch |
LPM |
M |
mm |
Kg |
| HA-3205 |
1 |
1/2 |
400 |
32 |
1-1/4″ |
100 |
20 |
1.2 |
126 x 126 x 463 |
9 |
| HA-3208 |
1 |
3/4 |
600 |
32 |
1-1/4″ |
100 |
30 |
1.2 |
126 x 126 x 485 |
9 |
| HA-3211 |
1 |
1.1 |
800 |
32 |
1-1/4″ |
100 |
40 |
1.2 |
126 x 126 x 511 |
10 |
| HA-3215 |
1 |
1.5 |
1100 |
32 |
1-1/4″ |
100 |
50 |
1.2 |
126 x 126 x 559 |
11 |
| HA-3218 |
1 |
1.8 |
1350 |
32 |
1-1/4″ |
100 |
60 |
1.2 |
126 x 126 x 583 |
11 |
