SC series
Product Features
- Whole pump is made of stainless steel SUS304. SUS316 is optional
- Vortex impeller with high pumping efficiency and reduce risk of jamming or clogging
- Mechanical seal design in oil chamber provides strong and reliable shaft sealing
- Can be used in pumping chemical liquid
- Robust construction
- Supplied with or without float switch
Applications
- Municipal wastewater
- Wastewater with content of fibres
- Draining of septic tanks, sumps and wastewater discharge tanks
- Drainage and groundwater
- Domestic wastewater
- Industrial wastewater
- Process and cooling water
- Emptying of tanks or reservoirs
- Emergency draining in flooded areas
Technical Data
- Max. flow rate: 1200 LPM (72 m³/h)
- Max. head: 23 m
- Max. particle size: 50 mm
- pH values: 6 to 8
- Power: 1/2 HP to 7. 5HP/ 0.37 kW to 5.5 kW
- Liquid Temp.: 0 °C to 60 °C/ +32 °F to +140 °F
- Degree of protection: IP 68
- Installation depth: Max. 8m below liquid level
- Material: Stainless steel
Performance Curve
Specifications
| Model |
Phase |
Output |
Outlet |
Max Flow |
Max Head |
Max. particle size |
Dimension |
Weight |
| HP |
kW |
mm |
inch |
LPM |
M |
mm |
Kg |
| SC-5005 |
1 |
1/2 |
0.37 |
50 |
2″ |
320 |
10 |
30 |
216 x 127 x 355 |
13 |
| SC-5010 |
1 |
1 |
0.75 |
50 |
2″ |
410 |
11 |
30 |
316 x 187 x 441 |
17 |
| SC-8020 |
1 |
2 |
1.5 |
80 |
3″ |
630 |
16 |
35 |
385 x 255 x 517 |
32 |
| SC-8030 |
3 |
3 |
2.2 |
80 |
3″ |
800 |
18 |
35 |
385 x 255 x 255 |
33 |
| SC-10050 |
3 |
5 |
3.7 |
100 |
4″ |
1100 |
20 |
45 |
486 x 290 x 629 |
50 |
| SC-10075 |
3 |
7.5 |
5.5 |
100 |
4″ |
1200 |
23 |
50 |
419 x 290 x 659 |
55 |
