SD series
Product Features
- 4-pole motor design
- Double mechanical seal design in oil chamber provides strong and reliable shaft sealing
- Robust construction
- Supplied with or without float switch
Applications
- Municipal wastewater
- Wastewater with content of fibres
- Draining of septic tanks, sumps and wastewater discharge tanks
- Drainage and groundwater
- Domestic wastewater
- Industrial wastewater
- Process and cooling water
- Emptying of tanks or reservoirs
- Emergency draining in flooded areas
Technical Data
- Max. flow rate: 2300 LPM (138 m³/h)
- Max. head: 21 m
- Max. particle size: 75 mm
- PH values: 6 to 8
- Power: 2 HP to 10 HP/ 1.5 kW to 7.5 kW
- Liquid Temp.: 0 °C to 40 °C/ +32 °F to +104 °F
- Degree of protection: IP 68
- Installation depth: Max. 8 m below liquid level
- Material: Cast iron
Performance Curve
Specifications
| Model |
Phase |
Output |
Outlet |
Max Flow |
Max Head |
Max. particle size |
Dimension |
Weight |
| HP |
kW |
mm |
inch |
LPM |
M |
mm |
Kg |
| SD-6520 |
1 |
2 |
1.5 |
65 |
2.5″ |
850 |
15 |
40 |
503 x 349 x 577 |
58 |
| SD-8020 |
1 |
2 |
1.5 |
80 |
3″ |
1000 |
12 |
50 |
537 x 368 x 599 |
62 |
| SD-8030 |
3 |
3 |
2.2 |
80 |
3″ |
1400 |
15 |
50 |
542 x 373 x 658 |
75 |
| SD-8050 |
3 |
5 |
3.7 |
80 |
3″ |
1700 |
18 |
48 |
567 x 399 x 688 |
92 |
| SD-10075 |
3 |
7.5 |
5.5 |
100 |
4″ |
2250 |
19 |
75 |
653 x 400 x 824 |
121 |
| SD-100100 |
3 |
10 |
7.5 |
100 |
4″ |
2300 |
21 |
75 |
653 x 400 x 824 |
125 |
