DB series
Product Features
- Compact design
- Lightweight and portable
- The motor is cooled by the pumped liquid
- Suitable for pumping sea water
- Supplied with or without float switch
Applications
- Sump and general drainage
- Pool emptying and fountains
- Residential and light commercial sewage applications
- Creating streams and waterfalls in your garden pond
- Removing rain or flood water from your floors and any other locations
Technical Data
- Max. flow rate: 140 LPM (8.4 m³/h)
- Max. head: 7 m
- Max. particle size: 5 mm
- pH values: 6 to 8
- Power: 1/4 HP/ 200 W
- Liquid Temp.: 0 °C to 40 °C/ +32 °F to +104 °F
- Degree of protection: IP 68
- Installation depth: Max. 6m below liquid level
- Material: GF/PP
Performance Curve
Specifications
Model |
Phase |
Output |
Outlet |
Max Flow |
Max
Head |
Max. particle size |
Dimension |
Weight |
HP |
W |
mm |
inch |
LPM |
M |
mm |
Kg |
DB-3202 |
1 |
1/4 |
200 |
32 |
1-1/4″ |
140 |
7 |
5 |
168 x 145 x 292 |
4 |
