DA series
Product Features
- Compact design
- Lightweight and portable
- The motor is cooled by the pumped liquid
- DA can pump down to 3 mm water level
- Suitable for pumping sea water
- Supplied with or without float switch
Applications
- Sump and general drainage
- Pool emptying and fountains
- Residential and light commercial sewage applications
- Creating streams and waterfalls in your garden pond
- Removing rain or flood water from your floors and any other locations
Technical Data
- Max. flow rate: 40 LPM (2.4 m³/h)
- Max. head: 4 m
- Max. particle size: 5 mm
- pH values: 6 to 8
- Power: 1/10 HP/ 80 W
- Liquid Temp.: 0 °C to 40 °C/ +32 °F to +104 °F
- Degree of protection: IP 68
- Installation depth: Max. 6 m below liquid level
- Material: GF/PP
Performance Curve
Specifications
| Model |
Phase |
Output |
Outlet |
Max Flow |
Max
Head |
Max. particle size |
Dimension |
Weight |
| HP |
W |
mm |
inch |
LPM |
M |
mm |
Kg |
| DA-2001 |
1 |
1/10 |
80 |
20 |
3/4″ |
40 |
4 |
5 |
114 x 114 x 239 |
3 |
