WS-30 series

WS-30 series

Product Features

  • 100% SUS 304 stainless steel made
  • Superior hydraulics, reliability and pumping efficiency
  • Longer lifetime
  • Strong, stainless-steel quality
  • Sand resistance

Applications

  • Irrigation/ water supply
  • Groundwater intake/ water supply
  • Dewatering (pasturage, sump, pond, and mining drainage, etc.)
  • Fountains
  • Pressure boosting

down-5down-4         down-7

down-3           down-8

分類: ,

Technical Data

  • 6″ pump
  • Capacity: 30 m³/h
  • Max. sand content: 50 g/m³
  • pH values: 6 to 8
  • Liquid Temp. up to 35 °C
  • Material:
    1. Impellers/Diffusers – SUS 304
    2. Shaft -SUS431QT

Performance Curve

50Hz

Model DISCH TOTAL HEAD CAPACITY HEAD LENGTH WEIGHT Required Power
(inch) (m) L/min M³/hr. (m) (mm) (kg) HP kW
WS-3002 3″ 24 500 30 16 449 6.5 3 2.2
WS-3003 3″ 34 500 30 21 545 8.2 4 3
WS-3004 3″ 45 500 30 28 641 9.9 5 3.7
WS-3006 3″ 69 500 30 42 833 13.8 7.5 5.5
WS-3008 3″ 90 500 30 57 1025 17.3 10 7.5
WS-3011 3″ 124 500 30 77.4 1313 22.7 15 11
WS-3013 3″ 146 500 30 91 1505 26.1 15 11
WS-3015 3″ 170 500 30 106 1697 29.6 20 15
WS-3017 3″ 190 500 30 122 1889 33.2 20 15
WS-3019 3″ 210 500 30 137 2081 36.7 25 18.5
WS-3021 3″ 235 500 30 152 2273 40.2 25 18.5
WS-3024 3″ 260 500 30 179 2561 45.3 30 22
WS-3026 3″ 290 500 30 192 2753 48.7 30 22
WS-3029 3″ 325 500 30 218 3041 53.8 35 26
WS-3032 3″ 358 500 30 243 3329 58.9 40 30
WS-3035 3″ 388 500 30 262 3617 64 40 30

60Hz

Model DISCH TOTAL HEAD CAPACITY HEAD LENGTH WEIGHT Required Power
(inch) (m) L/min M³/hr. (m) (mm) (kg) HP kW
WS-3001 3″ 18 500 30 12 353 4.8 2 1.5
WS-3002 3″ 32 500 30 24 449 6.5 4 3
WS-3003 3″ 48 500 30 36 545 8.2 6 4
WS-3004 3″ 67 500 30 50 641 9.9 7.5 5.5
WS-3005 3″ 80 500 30 64 737 11.6 10 7.5
WS-3007 3″ 115 500 30 91 929 15.6 12.5 9.3
WS-3008 3″ 130 500 30 104 1025 17.3 15 11
WS-3010 3″ 163 500 30 130 1121 20.9 17.5 13
WS-3011 3″ 180 500 30 143 1217 22.7 20 15
WS-3012 3″ 197 500 30 158 1409 24.5 25 18.5
WS-3014 3″ 227 500 30 183 1601 27.9 25 18.5
WS-3015 3″ 247 500 30 198 1697 29.6 30 22
WS-3017 3″ 278 500 30 219 1889 33 30 22
WS-3021 3″ 342 500 30 269 2273 39.8 40 30
WS-3023 3″ 378 500 30 292 2465 43.2 40 30
WS-3024 3″ 396 500 30 315 2561 44.9 50 37
WS-3026 3″ 425 500 30 341 2753 48.3 50 37
WS-3028 3″ 458 500 30 363 2945 51.7 50 37
WS-3029 3″ 478 500 30 383 3041 53.4 60 45
WS-3031 3″ 508 500 30 403 3233 56.8 60 45
WS-3033 3″ 540 500 30 429 3425 60.2 60 45
