Technical Data
- 6″ pump
- Capacity: 36 m³/h / 160 GPM
- Max. sand content: 50g/m³
- pH values: 6 to 8
- Liquid Temp. up to 35°C
- Material:
- Impellers – POM (WP05~35) / PC/GF(WP40~)
- Diffusers – PC/GF
WP-160 series
Product Features
- Floating impeller design for sand resistance and reducessand blocking
- Built-in check valve to prevent back flow
- SUS 304 polished stainless steel shell
- Shafts are made from hex 304 stainless steel bar material
- Built-in SUS 304 stainless steel strainer
Applications
- Residential potable water supply from deep wells
- Municipal and industrial water supply
- Irrigation and other agricultural applications
- Firefighting systems
- Pressure boosting in high-rise buildings and other applications
Performance Curve
50Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | M³/hr | HEAD | MOTOR | kW |
| inch | M | GPM | M | HP | |||
| WP-16003 | 3″ / 4″ | 33 | 160 | 36 | 26 | 5 | 3.7 |
| WP-16004 | 3″ / 4″ | 43 | 160 | 36 | 33 | 7.5 | 5.5 |
| WP-16005 | 3″ / 4″ | 55 | 160 | 36 | 42 | 10 | 7.5 |
| WP-16006 | 3″ / 4″ | 67 | 160 | 36 | 51 | 12.5 | 9 |
| WP-16007 | 3″ / 4″ | 76 | 160 | 36 | 58 | 15 | 11 |
| WP-16008 | 3″ / 4″ | 89 | 160 | 36 | 69 | 17.5 | 13 |
| WP-16009 | 3″ / 4″ | 99 | 160 | 36 | 76 | 20 | 15 |
60Hz
| Model | DISCH | TOTAL HEAD | CAPACITY | M³/hr | HEAD | MOTOR | kW |
| inch | M | GPM | M | HP | |||
| WP-16002 | 3″ / 4″ | 30 | 160 | 36 | 23 | 5 | 3.7 |
| WP-16003 | 3″ / 4″ | 46 | 160 | 36 | 37 | 7.5 | 5.5 |
| WP-16004 | 3″ / 4″ | 62 | 160 | 36 | 51 | 10 | 7.5 |
| WP-16005 | 3″ / 4″ | 79 | 160 | 36 | 66 | 15 | 11 |
| WP-16006 | 3″ / 4″ | 95 | 160 | 36 | 78 | 20 | 15 |
| WP-16009 | 3″ / 4″ | 142 | 160 | 36 | 120 | 25 | 18.5 |
