WP-15 series

Product Features

  • Floating impeller design for sand resistance and reducessand blocking
  • Built-in check valve to prevent back flow
  • SUS 304 polished stainless steel shell
  • Shafts are made from hex 304 stainless steel bar material
  • Built-in SUS 304 stainless steel strainer

Applications

  • Residential potable water supply from deep wells
  • Municipal and industrial water supply
  • Irrigation and other agricultural applications
  • Firefighting systems
  • Pressure boosting in high-rise buildings and other applications

down-5down-4        down-7

down-3       down-8

分類: ,

Technical Data

  • 4″ pump
  • Capacity: 3.4 m³/h / 15 GPM
  • Max. sand content: 50g/m³
  • pH values: 6 to 8
  • Liquid Temp. up to 35°C
  •  Material:
    1. Impellers – POM (WP05~35)  / PC/GF(WP40~)
    2. Diffusers – PC/GF

Performance Curve

WP-15-50Hz WP-15-60Hz

50Hz

Model DISCH TOTAL
HEAD		 CAPACITY M³/hr HEAD MOTOR kW
inch M GPM M HP
WP-1506 1-1/4″/1-1/2″/2″ 50 15 3.4 29 0.5 0.37
WP-1508 1-1/4″/1-1/2″/2″ 69 15 3.4 40 0.75 0.55
WP-1509 1-1/4″/1-1/2″/2″ 78 15 3.4 44 1 0.75
WP-1513 1-1/4″/1-1/2″/2″ 112 15 3.4 67 1.5 1.1
WP-1517 1-1/4″/1-1/2″/2″ 146 15 3.4 86 2 1.5
WP-1526 1-1/4″/1-1/2″/2″ 221 15 3.4 123 3 2.2
WP-1531 1-1/4″/1-1/2″/2″ 270 15 3.4 160 4 3
WP-1537 1-1/4″/1-1/2″/2″ 317 15 3.4 182 5 3.7
WP-1541 1-1/4″/1-1/2″/2″ 364 15 3.4 212 5.5 4

60Hz

Model DISCH TOTAL
HEAD		 CAPACITY M³/hr HEAD MOTOR kW
inch M GPM M HP
WP-1505 1-1/4″/1-1/2″/2″ 63 15 3.4 43 0.5 0.37
WP-1506 1-1/4″/1-1/2″/2″ 79 15 3.4 55 0.75 0.55
WP-1507 1-1/4″/1-1/2″/2″ 91 15 3.4 63 1 0.75
WP-1509 1-1/4″/1-1/2″/2″ 116 15 3.4 81 1.5 1.1
WP-1513 1-1/4″/1-1/2″/2″ 166 15 3.4 114 2 1.5
WP-1517 1-1/4″/1-1/2″/2″ 217 15 3.4 149 3 2.2
WP-1526 1-1/4″/1-1/2″/2″ 329 15 3.4 221 5 3.7
