Technical Data
- Volume flow
40 to 48 m³/hr
0.5 to 20 mbar - CE approval
- Insulation Class: F (155°C)
- Degree of Protection: IP 54
- Mounting: Horizontal
- Voltage Tolerance: ±10% of nominal U
VC series
Product Features
- Quality components lead quiet, low-vibration and fast pumping speed operation
- Compact, reliable design leads easy installation and maintenance
- Multi-stage filtration system ensures minimum leakage (less 0.1%) of lubrication oil
- Air cooling, internal oil recirculation allows this pump to be used in any environment
- Long, service-free life
Applications
- Vacuum packaging
- Food technology
- Wood working
- Pneumatic conveying
- Transport and lifting systems
- Plastics industry
Performance Curve
50Hz
| Model | Phase | Ultimate Pressure | Maximum Pumping Speed | Motor ratings | Noise Level | Oil Capacity | Weight | ||
| Rated output | Voltage | Rated Current | |||||||
| mbar | m³/hr | kW | V | Amps | dB(A) | L | kg | ||
| VC-5T1 | 3 | 0.5 | 40 | 1.1 | 200-240 / 380-440 | 5.4-6.4 / 3.4-4.2 | 70 | 1 | 50 |
| VC-5T2 | 3 | 20 | 40 | 1.1 | 200-240 / 380-440 | 5.4-6.4 / 3.4-4.2 | 70 | 1 | 50 |
60Hz
| Model | Phase | Ultimate Pressure | Maximum Pumping Speed | Motor ratings | Noise Level | Oil Capacity | Weight | ||
| Rated output | Voltage | Rated Current | |||||||
| mbar | m³/hr | kW | V | Amps | dB(A) | L | kg | ||
| VC-6T1 | 3 | 0.5 | 48 | 1.5 | 200-240 / 380-440 | 5.2-5.5 / 3.0-4.2 | 74 | 1 | 50 |
| VC-6T2 | 3 | 20 | 48 | 1.5 | 200-240 / 380-440 | 5.2-5.5 / 3.0-4.2 | 74 | 1 | 50 |
