VB series

Product Features

  • Quality components lead quiet, low-vibration and fast pumping speed operation
  • Compact, reliable design leads easy installation and maintenance
  • Multi-stage filtration system ensures minimum leakage (less 0.1%) of lubrication oil
  • Air cooling, internal oil recirculation allows this pump to be used in any environment
  • Long, service-free life

Applications

  • Vacuum packaging
  • Food technology
  • Wood working
  • Pneumatic conveying
  • Transport and lifting systems
  • Plastics industry

down-1        down-2

分類:

Technical Data

  • Volume flow
    20 to 24 m³/hr
    2 to 20 mbar
  • CE approval
  • Insulation Class: F (155°C)
  • Degree of Protection: IP 54
  • Mounting: Horizontal
  • Voltage Tolerance: ±10% of nominal U

Performance Curve

VB-performance

50Hz

Model Phase Ultimate Pressure Maximum Pumping Speed Motor ratings Noise Level Oil Capacity Weight
Rated output Voltage Rated Current
mbar m³/hr kW V Amps dB(A) L kg
VB-5S1 1 2 20 0.76 100-120 / 200-240 7.5-12.2 / 4-6.8 72 0.5 25.3
VB-5S2 1 2 20 0.76 100 9.2 72 0.5 25.3
VB-5S3 1 2 20 0.76 200-240 4-6.8 72 0.5 24.4
VB-5S4 1 20 20 0.76 100-120 / 200-240 7.5-12.2 / 4-6.8 72 0.5 25.3
VB-5S5 1 20 20 0.76 200-240 4-6.8 72 0.5 24.4
VB-5T1 3 2 20 0.76  200-240 / 380-440 2.5-2.9 / 1.5-1.9 72 0.5 21.9
VB-5T2 3 20 20 0.76  200-240 / 380-440 2.5-2.9 / 1.5-1.9 72 0.5 21.9

60Hz

Model Phase Ultimate Pressure Maximum Pumping Speed Motor ratings Noise Level Oil Capacity Weight
Rated output Voltage Rated Current
mbar m³/hr kW V Amps dB(A) L kg
VB-6S2 1 2 24 0.92 100 10.8 72 0.5 25.3
VB-6S3 1 2 24 0.92 200-240 4.6-4 72 0.5 24.4
VB-6S4 1 20 24 0.92 100-120 / 200-240 9.8-9.0 / 5.3-4.8 72 0.5 25.3
VB-6S5 1 20 24 0.92 200-240 4.6-4 72 0.5 24.4
VB-6T1 3 2 24 0.92  200-240 / 380-440 2.7-2.5 / 1.6-1.5 72 0.5 21.9
VB-6T2 3 20 24 0.92  200-240 / 380-440 2.7-2.5 / 1.6-1.5 72 0.5 21.9
