Technical Data
- Volume flow
8 to 9.6 m³/hr
2 mbar - CE approval
- Insulation Class: B (130°C)
- Degree of Protection: IP 20
- Mounting: Horizontal
- Voltage Tolerance: ±10% of nominal U
VA series
Product Features
- Quality components lead quiet, low-vibration and fast pumping speed operation
- Compact, reliable design leads easy installation and maintenance
- Multi-stage filtration system ensures minimum leakage (less 0.1%) of lubrication oil
- Air cooling, internal oil recirculation allows this pump to be used in any environment
- Long, service-free life
Applications
- Vacuum packaging
- Food technology
- Wood working
- Pneumatic conveying
- Transport and lifting systems
- Plastics industry
Performance Curve
50Hz
| Model | Phase | Ultimate Pressure | Maximum Pumping Speed | Motor ratings | Noise Level | Oil Capacity | Weight | ||
| Rated output | Voltage | Rated Current | |||||||
| mbar | m³/hr | kW | V | Amps | dB(A) | L | kg | ||
| VA-5S1 | 1 | 2 | 8 | 0.35 | 200-240 | 2.4 | 59 | 0.25 | 9.5 |
| VA-5S2 | 1 | 2 | 8 | 0.35 | 110 | 5.5 | 60 | 0.25 | 9.5 |
| VA-5S3 | 1 | 2 | 8 | 0.35 | 100 | 4.4 | 60 | 0.25 | 9.5 |
60Hz
| Model | Phase | Ultimate Pressure | Maximum Pumping Speed | Motor ratings | Noise Level | Oil Capacity | Weight | ||
| Rated output | Voltage | Rated Current | |||||||
| mbar | m³/hr | kW | V | Amps | dB(A) | L | kg | ||
| VA-6S1 | 1 | 2 | 9.6 | 0.45 | 200-240 | 2.5 | 63 | 0.25 | 9.5 |
| VA-6S2 | 1 | 2 | 9.6 | 0.45 | 110 | 6.2 | 64 | 0.25 | 9.5 |
| VA-6S3 | 1 | 2 | 9.6 | 0.45 | 100 | 6.8 | 64 | 0.25 | 9.5 |
