WS-95 series

Product Features

  • 100% SUS 304 stainless steel made
  • Superior hydraulics, reliability and pumping efficiency
  • Longer lifetime
  • Strong, stainless-steel quality
  • Sand resistance

Applications

  • Irrigation/ water supply
  • Groundwater intake/ water supply
  • Dewatering (pasturage, sump, pond, and mining drainage, etc.)
  • Fountains
  • Pressure boosting

down-5down-4         down-7

down-3           down-8

分類: ,

Technical Data

  • 8″ pump
  • Capacity: 95 m³/h
  • Max. sand content: 50 g/m³
  • pH values: 6 to 8
  • Liquid Temp. up to 35 °C
  • Material:
    1. Impellers/Diffusers – SUS 304
    2. Shaft -SUS431QT

Performance Curve

50Hz

Model DISCH TOTAL HEAD CAPACITY HEAD LENGTH WEIGHT Required Power
(inch) (m) L/min M³/hr. (m) (mm) (kg) HP kW
WS-9501 5″ 22 600 36 12 618 25.1 7.5 5.5
WS-9502 5″ 43 600 36 24 746 28.7 12.5 9.3
WS-9503 5″ 65 600 36 34 874 32.3 17.5 13
WS-9504 5″ 84 600 36 48 1003 35.9 25 18.5
WS-9505 5″ 106 600 36 58 1131 39.5 30 22
WS-9506 5″ 128 600 36 71 1259 43 35 26
WS-9507 5″ 147 600 36 84 1387 46.6 40 30
WS-9508 5″ 170 600 36 92 1515 50.2 50 37
WS-9509 5″ 190 600 36 105 1644 53.8 50 37
WS-9510 5″ 215 600 36 119 1783 58.8 60 45
WS-9511 5″ 238 600 36 136 1911 62.4 75 55
WS-9512 5″ 260 600 36 146 2039 66 75 55
WS-9513 5″ 280 600 36 155 2168 69.6 75 55
WS-9514 5″ 301 600 36 170 2296 73.2 85 63
WS-9515 5″ 325 600 36 184 2424 76.7 100 75
WS-9517 5″ 365 600 36 204 2680 84 100 75
WS-9518 5″ 388 600 36 218 2809 87.6 125 93
WS-9520 5″ 431 600 36 238 3065 94.8 125 93

60Hz

Model DISCH TOTAL HEAD CAPACITY HEAD LENGTH WEIGHT Required Power
(inch) (m) L/min M³/hr. (m) (mm) (kg) HP kW
WS-9501 5″ 32 700 42 18 618 25.1 10 7.5
WS-9502 5″ 62 700 42 39 746 28.7 17.5 13
WS-9503 5″ 93 700 42 58 874 32.3 30 22
WS-9504 5″ 123 700 42 80 1003 35.9 35 26
WS-9505 5″ 155 700 42 101 1131 39.5 50 37
WS-9506 5″ 182 700 42 121 1259 43 50 37
WS-9507 5″ 215 700 42 141 1398 48 60 45
WS-9508 5″ 245 700 42 165 1527 51.6 75 55
WS-9509 5″ 278 700 42 186 1655 55.2 85 63
WS-9510 5″ 310 700 42 206 1783 58.8 85 63
WS-9511 5″ 341 700 42 228 1911 62.4 100 75
WS-9512 5″ 372 700 42 247 2039 66 125 93
WS-9513 5″ 407 700 42 267 2168 69.6 155 93
