WP-10 series

Product Features

  • Floating impeller design for sand resistance and reducessand blocking
  • Built-in check valve to prevent back flow
  • SUS 304 polished stainless steel shell
  • Shafts are made from hex 304 stainless steel bar material
  • Built-in SUS 304 stainless steel strainer

Applications

  • Residential potable water supply from deep wells
  • Municipal and industrial water supply
  • Irrigation and other agricultural applications
  • Firefighting systems
  • Pressure boosting in high-rise buildings and other applications

down-5down-4        down-7

down-3       down-8

分類: ,

Technical Data

  • 4″ pump
  • Capacity: 2 m³/h / 10 GPM
  • Max. sand content: 50g/m³
  • pH values: 6 to 8
  • Liquid Temp. up to 35°C
  •  Material:
    1. Impellers – POM (WP05~35)  / PC/GF(WP40~)
    2. Diffusers – PC/GF

Performance Curve

WP-10-50Hz WP-10-60Hz

50Hz

Model DISCH TOTAL HEAD CAPACITY M³/hr HEAD MOTOR kW
inch M GPM M HP
WP-1006 1-1/4″/1-1/2″/2″ 50 10 2 24 0.5 0.37
WP-1009 1-1/4″/1-1/2″/2″ 78 10 2 40 0.75 0.55
WP-1012 1-1/4″/1-1/2″/2″ 101 10 2 51 1 0.75
WP-1017 1-1/4″/1-1/2″/2″ 143 10 2 71 1.5 1.1
WP-1022 1-1/4″/1-1/2″/2″ 187 10 2 93 2 1.5
WP-1030 1-1/4″/1-1/2″/2″ 255 10 2 129 3 2.2
WP-1040 1-1/4″/1-1/2″/2″ 340 10 2 171 4 3

60Hz

Model DISCH TOTAL HEAD CAPACITY M³/hr HEAD MOTOR kW
inch M GPM M HP
WP-1006 1-1/4″/1-1/2″/2″ 71 10 2 43 0.5 0.37
WP-1007 1-1/4″/1-1/2″/2″ 87 10 2 55 0.75 0.55
WP-1009 1-1/4″/1-1/2″/2″ 111 10 2 70 1 0.75
WP-1013 1-1/4″/1-1/2″/2″ 157 10 2 99 1.5 1.1
WP-1017 1-1/4″/1-1/2″/2″ 206 10 2 128 2 1.5
WP-1023 1-1/4″/1-1/2″/2″ 283 10 2 177 3 2.2
WP-1030 1-1/4″/1-1/2″/2″ 371 10 2 223 4 3
WP-1035 1-1/4″/1-1/2″/2″ 428 10 2 250 5 3.7
