SB series
Product Features
- 2-pole motor design with strong torque
- Vortex impeller with high pumping efficiency and reduce risk of jamming or clogging
- Double mechanical seal design in oil chamber provides strong and reliable shaft sealing
- Robust construction
- Supplied with or without float switch
Applications
- Municipal wastewater
- Wastewater with content of fibres
- Draining of septic tanks, sumps and wastewater discharge tanks
- Drainage and groundwater
- Domestic wastewater
- Industrial wastewater
- Process and cooling water
- Emptying of tanks or reservoirs
- Emergency draining in flooded areas
Technical Data
- Max. flow rate: 1100 LPM (66 m³/h)
- Max. head: 22 m
- Max. particle size: 55 mm
- PH values: 6 to 8
- Power: 1 HP to 5 HP/ 0.75 kW to 3.7 kW
- Liquid Temp.: 0 °C to 40 °C/ +32 °F to +104 °F
- Degree of protection: IP 68
- Installation depth: Max. 8 m below liquid level
- Material: Cast iron
Performance Curve
Specifications
| Model |
Phase |
Output |
Outlet |
Max Flow |
Max Head |
Max. particle size |
Dimension |
Weight |
| HP |
kW |
mm |
inch |
LPM |
M |
mm |
Kg |
| SB-5010 |
1 |
1 |
0.75 |
50 |
2″ |
320 |
14 |
33 |
271 x 218 x 400 |
21 |
| SB-5020 |
1 |
2 |
1.5 |
50 |
2″ |
420 |
22 |
31 |
271 x 218 x 443 |
30 |
| SB-6520 |
1 |
2 |
1.5 |
65 |
2.5″ |
700 |
17 |
45 |
398 x 244 x 600 |
46 |
| SB-8030 |
3 |
3 |
2.2 |
80 |
3″ |
1100 |
20 |
50 |
449 x 281 x 723 |
64 |
| SB-8050 |
3 |
5 |
3.7 |
80 |
3″ |
1100 |
22 |
55 |
449 x 281 x 723 |
68 |
