IB series
Product Features
- Entirely made of AISI 304 or AISI316 stainless steel
- Quality material inside and robust construction
- Builed-in thermal protector
- Can be used in pumping chemical liquid
- The motor is cooled by the pumped liquid
- Supplied with or without float switch
Applications
- Groundwater lowering
- Drainage of cellars or buildings
- Pumping of domestic wastewater without toilet waste
- Emptying applications, e.g. in pools, tanks and vessels
- Pumping applications within agriculture, the dairy industry, horticulture and the process industry
Technical Data
- Max. flow rate: 300 LPM (18 m³/h)
- Max. head: 15 m
- Max. particle size: 10 mm
- pH values: 6 to 8
- Power: 1/3 HP to 1 HP / 250 W to 750 W
- Liquid Temp.: 0 °C to 60 °C/ +32 °F to +140 °F
- Degree of protection: IP 68
- Installation depth: Max. 8 m below liquid level
- Material: Stainless steel
Performance Curve
Specifications
| Model |
Phase |
Output |
Outlet |
Max Flow |
Max Head |
Max. particle size |
Dimension |
Weight |
| HP |
W |
mm |
inch |
LPM |
M |
mm |
Kg |
| IB-5003 |
1 |
1/3 |
250 |
50 |
2″ |
220 |
9 |
7 |
181 x 181 x 340 |
12 |
| IB-5005 |
1&3 |
1/2 |
400 |
50 |
2″ |
240 |
11 |
10 |
181 x 181 x 340 |
12 |
| IB-5010 |
1&3 |
1 |
750 |
50 |
2″ |
300 |
15 |
10 |
181 x 181 x 343 |
15 |
